    BMSY-250-W-FD-D China Factory BMSY Series Hydraulic Orbit Motor Supplier

    Ask Lasest Price
    Brand Name : HANJIU
    Model Number : BMSY-250-W-FD-D
    Certification : CE, ISO9001
    Price : Contact the selle to get the best offer
    Payment Terms : T/T, Western Union
    Supply Ability : 10000 pieces per year
    Delivery Time : 35 - 45 work days
    • Product Details
    • Company Profile

    BMSY-250-W-FD-D China Factory BMSY Series Hydraulic Orbit Motor Supplier


    BMSY-250-W-FD-D, China Factory, BMSY series Hydraulic Orbit Motor Supplier


    Welcome!


    Hydraulic Motor manufacturer from China specializes in high performance bidirectional hydraulic motors for

    mixing, sweeping, lifting, conveying and various applications.

    Partners include OEM, hydraulic importers, hydraulic distributors


    Please see product introduction below:


    BMSY-250-W-FD-D

    displacement250ml/r
    flange4-13.5 wheel Mount
    portsG1/2 Manifold Mount 2-M10,G1/4
    output shaftLong Shaft O31.75,
    splined key 14-DP12/24
    rotationCW and CCW
    paintblack




    Specification:


    Main Specifications:
    TypeBMSY
    BMSE
    80
    BMSY
    BMSE
    100
    BMSY
    BMSE
    125
    BMSY
    BMSE
    160
    BMSY
    BMSE
    200
    BMSY
    BMSE
    250
    BMSY
    BMSE
    315
    BMSY
    BMSE
    375
    Geometric displacement
    (cm3 /rev.)
    80.6100.8125157.2200252314.5370
    Max. speed (rpm)cont.800748600470375300240200
    int.988900720560450360280240
    Max. torque (N·m)cont.190240310316400450560536
    int.240300370430466540658645
    peak260320400472650690740751
    Max. output (kW)cont.15.918.819.515.615.714.114.111.8
    int.20.123.523.221.218.31718.917
    Max. pressure drop (MPa)cont.17.517.517.5151412.51210
    int.2121212116161412
    peak22.522.522.522.522.52018.514
    Max. flow (L/min)cont.6575757575757575
    int.8090909090909090
    Max. inlet pressure (MPa)cont.2525252525252525
    int.3030303030303030
    Weight (kg)9.81010.310.711.111.612.312.6

    * Continuous pressure :Max. value of operating motor continuously.
    * Intermittent pressure :Max. value of operating motor in 6 seconds per minute.
    * Peak pressure:Max. value of operating motor in 0.6 second per minute.


    Mounting size of : BMSY-250-W-FD-D




    More mounting sizes available for BMSY series:



    More BMSY series motors available:


    Contact us to learn more about BMSY series hydraulic motors
    Welcome to send your original equipment code, which can help us quickly match the model suitable for your business
    We hope that our experience and technology can create value for you.
