Industrial Online Residual Chlorine Analyzer Disinfection Water Quality Controller

    Buy cheap Industrial Online Residual Chlorine Analyzer Disinfection Water Quality Controller from wholesalers

    Buy cheap Industrial Online Residual Chlorine Analyzer Disinfection Water Quality Controller from wholesalers
    • Buy cheap Industrial Online Residual Chlorine Analyzer Disinfection Water Quality Controller from wholesalers

    Industrial Online Residual Chlorine Analyzer Disinfection Water Quality Controller

    Ask Lasest Price
    Brand Name : JUGE
    Model Number : None
    Certification : IOS9001, CE
    Price : USD100-500
    Delivery Time : 5-8 working days
    Payment Terms : Online order, T/T
    Supply Ability : 100 Unit/Week
    • Product Details
    • Company Profile

    Industrial Online Residual Chlorine Analyzer Disinfection Water Quality Controller

    Industrial Online Residual Chlorine Analyzer Disinfection Water Quality Controller


    >>Overview
    The industrial online residual chlorine analyzer is a microprocessor-based online water quality monitoring and control instrument. It is widely used in various industrial processes such as drinking water treatment plants, drinking water distribution networks, swimming pools, water treatment projects, wastewater treatment, and water disinfection to continuously monitor and control residual chlorine levels and temperature values in aqueous solutions.


    >>Features
    • ‌Dot-matrix LCD‌ display
    • ‌Smart menu operation
    • ‌Multiple automatic calibration functions
    • ‌Versatile signal output options, 4-20mA, RS485

    • ‌Data recording & curve display‌
    • ‌Differential signal measurement mode‌ for stable and reliable performance
    • ‌Manual/automatic temperature compensation
    • ‌Relay control switches
    • ‌High/low limits with hysteresis control
    • ‌Simultaneous display‌ of main Parameter, temperature, and status on the same interface
    • ‌Password protection‌ to prevent unauthorized operation


    >>Technical Parameter

    Controller Type

    98*98cm

    black and white version

    98*98cm

    colorful version

    144*144cm

    black and white version

    144*144cm

    colorful version

    Measurement Range

    (depends on electrode)

    0~20.00mg/L(ppm)

    Temperature: -10~150.0 °C;

    Resolution

    0.001/0.01mg/L;

    Temperature: 0.1 °C;

    Basic Error

    ±1%F.S

    Temperature: ±0.3°C

    Response time

    90%<90s

    Current Output

    0/4-20 mA (load resistance <750 Ω)

    20-4 mA (load resistance <750 Ω)

    (1 channel standard, 2 channels optional)

    0/4-20 mA (load resistance <750 Ω)

    20-4 mA (load resistance <750 Ω)

    Communication OutputRS485 MODBUS RTU

    Dual Relay Control Contacts

    2Sets

    3A 250V AC, 3A 30V DC

    3Sets

    5A 250V AC, 3A 30V DC

    Power Supply‌ (optional)

    85-265 VAC ±10%, 50±1 Hz, ≤3W

    9-36 VDC, ≤3W

    Historical Data

    NO

    NO

    Yes

    Yes

    Data Trend Chart

    NO

    NO

    NO

    Yes

    Dimensions98 × 98 × 130 mm144 × 144 × 118 mm
    InstallationPanel-mounted or wall-mounted, Panel cutout: 92.5 × 92.5 mmPanel-mounted or wall-mounted, Panel cutout: 137 × 137 mm
    Protection RatingIP65
    Weight0.6 kg0.8 kg

    Operating Environment

    Temperature: -10 to 60°C

    Humidity: ≤90% RH

    No strong magnetic interference except Earth’s natural field
