    2DT650GZ-B Dual Axis Tracking Turntable Optoelectronic Device

    Ask Lasest Price
    Brand Name : RUYA
    Model Number : 2DT650GZ-B
    Certification : ISO 9001
    Price : negotiable
    Payment Terms : T/T
    Supply Ability : ≤3 sets, 3 months
    Delivery Time : 3-4 months
    • Product Details
    • Company Profile

    2DT650GZ-B Dual Axis Tracking Turntable Optoelectronic Device

    DT650GZ-B Dual-axis Tracking Turntable Optoelectronic Device


    Product Description


    2DT650GZ-B optoelectronic device consists of a mechanical platform and a control box. The control box and the mechanical platform are connected through cables. The control box has an RS422 communication interface and can communicate with the host computer.

    The mechanical platform body adopts an up-and-down vertical structure. The upper part is the pitch axis component and the lower part is the azimuth axis component. The control box has circuit modules such as angle resolution, motor drive, power conversion, and serial communication.


    Product Parameters


    Specification

    1

    Load Weight

    100Kg

    2

    Table Diameter

    Ф650mm

    3

    Table Flatness

    0.02mm

    4

    Table Runout

    0.02mm

    5

    Rotary Accuracy Of Dual-Axis

    ±3

    6

    Perpendicularity Of Dual-Axis

    ±3

    7

    Intersection Of Dual-Axis

    Ф0.5mm diameter ball

    8

    Positioning Error Of Angular Position

    outer frame:±5″

    inner frame:±5″

    9

    Positioning Repeatability Of Angular Position

    ±2″

    10

    Rate Range

    inner frame:0.001°/s~100°/s

    outer frame:0.001°/s~100°/s

    11

    Angle Rotary Range

    outer frame:continuous rotation

    inner frame:±90°

    12

    Rate Accuracy

    ω≤1°/s , 2×10-3 (1° average)

    1°/s≤ω<10°/s , 2×10-4 (10° average)

    ω≥10°/s , 2×10-5 (360° average)

    13

    Maximum Angular Acceleration

    inner frame:≥30°/s²

    outer frame:≥30°/s²
