    3DT400FZ/WK 3 Axis Simulation Temperature Control Test Turntable

    Ask Lasest Price
    Brand Name : RUYA
    Model Number : 3DT400FZ/WK
    Certification : ISO 9001
    Price : negotiable
    Payment Terms : T/T
    Supply Ability : ≤3 sets,4 months
    Delivery Time : 3-4 months
    • Product Details
    • Company Profile

    3DT400FZ/WK 3 Axis Simulation Temperature Control Test Turntable

    3DT400FZ/WK 3-axis Simulation Temperature Control Turntable


    Product Description


    The three-axis simulation temperature control turntable is a highly integrated experimental equipment, mainly used for product and environmental adaptability testing in aerospace, automobile manufacturing, materials science and other fields. It can simulate various complex environments that may be encountered in practical use, such as temperature, humidity, vibration, etc., in order to test the performance and reliability of products under these conditions.


    Product Parameters


    Specification

    1

    Load Weight

    30Kg

    2

    Table Diameter

    Ф400mm

    3

    Table Flatness

    0.02mm

    4

    Table Runout

    0.02mm

    5

    Rotary Accuracy Of Three-Axis

    ±3

    6

    Perpendicularity Of Three-Axis

    ±3

    7

    Intersection Of Three-Axis

    Ф0.5mm diameter ball

    8

    Positioning Error Of Angular Position

    ±2″

    9

    Positioning Repeatability Of Angular Position

    ±2″

    10

    Rate Range

    inner frame:0.01°/s~1800°/s

    middle frame:0.01°/s~500°/s

    outer frame:0.01°/s~500°/s

    11

    Rate Accuracy

    ω≤1°/s , 2×10-3 (1° average)

    1°/s≤ω<10°/s , 2×10-4 (10° average)

    ω≥10°/s , 2×10-5 (360°average)

    12

    Maximum Angular Acceleration

    inner frame:≥2000°/s²

    middle frame:≥1200°/s²

    outer frame:≥800°/s²

    13

    User Slip Ring

    Customizable

    14

    System Bandwidth (Double Ten)

    inner frame:12Hz

    middle frame:≥6Hz

    outer frame:≥6Hz

    15

    Temperature Range

    -50°C~120°C

    16

    Temperature Error

    ±1°C

    17

    Temperature Fluctuation

    ±1°C

    18

    Temperature Uniformity

    ±2°C

    19

    Maximum Heating And Cooling Rate

    ≥3°C/min

    20

    Dimensions Inside The Box

    450mm x 450mmx 450mm
