    120W 200W Multi-functional Automatic Large Format Precision Smart LED Mirror Glass Laser Sandblasting Drilling Paint Removing Machine

    Ask Lasest Price
    Brand Name : Perfect Laser
    Model Number : PEDB-190
    Certification : CE /ISO /TUV /SGS
    Price : Negotiable
    Payment Terms : L/C, , T/T, Western Union, MoneyGram
    Supply Ability : 400 sets per month
    Delivery Time : 3-7 working days
    • Product Details
    • Company Profile

    120W 200W Multi-functional Automatic Large Format Precision Smart LED Mirror Glass Laser Sandblasting Drilling Paint Removing Machine

    120W 200W Multi-functional Automatic Large Format Precision Smart LED Mirror Glass Laser Sandblasting Drilling Paint Removing Machine

    Model: PEDB-190


    Machine Introduction


    The laser glass sanding machine utilizes cutting-edge laser technology, precisely controlling the energy and focus of the laser beam to achieve highly efficient material surface processing. It surpasses traditional sandblasting methods by addressing issues such as complex procedures, pollution, and low yield rates.

    Using a non-contact laser etching process, it completes intricate graphic designs for light-transmitting and switch button areas in a single step. With integrated drilling and film removal functions, this multifunctional machine significantly reduce business costs, promotes eco-friendliness, and leads the way in a new era of intelligent mirror sandblasting.


    Product Features


    • High Efficiency and Energy Savings: The laser glass sandblasting machine features a premium MOPA fiber laser, delivering exceptional precision and speed. Its compact size and low power consumption strike the perfect balance between high performance and eco-friendliness.
    • Simplified Workflow: The laser glass sandblasting machine uses a laser processing technology, completing product processing in a single step, which effectively improves production efficiency and flexibility.
    • Large Processing Area: With a working area of up to 2.5m x 1.6m, it supports custom sizes to meet diverse smart mirror production needs.
    • Stable and Reliable Operation: Designed for 24/7 continuous use, it ensures consistent performance with a maintenance-free design, zero consumables, and pollution-free operation for worry-free production.
    • Versatile Processing and Customization: From silver mirrors and aluminum mirrors to eco-friendly glass, the laser glass sandblasting machine supports a wide range of materials. It offers personalized solutions with features like automated loading and unloading, multi-station operation, visual positioning, and modular configuration—perfect for fully automated, unattended mass production tailored to unique customer needs.

    Application:

    It’s widely used in construction, automobiles, daily necessities, home furnishings, electronics, instruments and other fields.



    Technical Data:


    Product nameMirror Laser Sandblasting Drilling Paint Removing Machine
    Laser typeAnti-high reflection fiber laser source
    Laser power120W/200W can be customized
    Laser wavelength1064nm
    How it worksManual loading, automatic processing
    Processing timeDepends on the product
    XY equipment effective travel2500*1600mm can be customized
    Drilling sizeφ1-50mm
    Processing accuracy±0.03mm, no splicing marks
    Film removal speed0.5m/min, line width 3mm
    Sand blasting speed0-40m/min
    Processing thickness3-8mm
    Processing product sizeMaximum 2500 * 1600mm
    Laser system cooling methodWater Cooling
    Dust collection systemCustomized hole dust extraction structure
    System gas0.6-0.8MPa
    System power consumptionAC220V 50/60HZ
    Overall dimensions2480x3800x1785mm
    Machine weight≤2T
