    Static-Dissipative PE/PP Packaging Film for Electronics 30-200μm Custom Widths

    Ask Lasest Price
    Brand Name : Bright Pack
    Certification : patent for invention、BRC、GRS、ISO、FDA、QC
    Price : $3.2-3.8/kg
    Payment Terms : T/T,Western Union
    Supply Ability : 2000kg/day
    Delivery Time : 8-15work days
    • Product Details
    • Company Profile

    Static-Dissipative PE/PP Packaging Film for Electronics 30-200μm Custom Widths

    Designed for sensitive electronic components, our static-dissipative PE/PP packaging film provides reliable ESD protection during storage and transportation. This multi-layer film combines permanent anti-static properties with excellent clarity and mechanical strength, making it ideal for PCB, semiconductor, and microelectronics packaging.


    Key Features:


    Permanent Anti-Static – Surface resistivity: 10⁹–10¹¹ Ω/sq (ASTM D257)
    High Transparency – >90% light transmission for easy inspection (ASTM D1003)
    Customizable Widths – Available from 200mm to 2000mm (±1mm tolerance)
    Dual-Layer Protection – Outer PP for durability + inner PE for heat sealing
    ESD-Safe – Meets ANSI/ESD S20.20 & IEC 61340-5-1 standards


    Applications:
    • Integrated circuits (ICs) & microchips
    • Automotive electronics
    • Medical device packaging
    • Aerospace components


    Technical Specifications Table

    PropertySpecificationTest Method
    Material Composition3-layer coextruded PE/PP + anti-static additive
    Thickness Range30–200μm (custom up to 300μm)ASTM D6988
    Surface Resistivity10⁹–10¹¹ Ω/sqESD STM11.11
    Decay Time (5kV→100V)<2 secondsANSI/ESD STM11.31
    Tensile Strength (MD/CD)28MPa/22MPaASTM D882
    Elongation at Break500% (MD) / 600% (CD)ASTM D882
    Heat Seal Temperature120–160°CASTM F2029
    Light Transmission≥90%ASTM D1003
