2 Ton Hand Chain Blocks Lifting Tool Hook Type Chain Block
Description:
This chain block is a portable lifting device easily operated by
hand chain. It is suitable for use in factories, mines, farms,
construction sites, wharves, docks and warehouses for installation
of equipment, as well as for loading and unloading goods.
The upper and lower hooks of the chain hoist are made of alloy
steel, which can be bent without breaking directly after
overloading, which is thick and durable.
Standard Features:
- Safety in operation with minimum maintenance.
- High efficiency and labour saving.
- Light weight and easy handling.
- Fine appearance with small size.
- Durable and long life service.
Specifications:
| Model | DZ121 | DZ251 | DZ161 | DZ321 | DZ252 | DZ501 | DZ1001 | DZ2001 |
| Rated Capacity(ton) | 0.125 | 0.25 | 0.16 | 0.32 | 0.25 | 0.5 | 1 | 2 |
| Testing Load(ton) | 0.16 | 0.32 | 0.2 | 40 | 0.32 | 0.63 | 1.25 | 2.5 |
| Standard Lift(m) | 3 | 3 | 3 | 3 | 3 | 3 | 3 | 3 |
| Lift Speed Fast(m/min) | 8 | 4 | 12 | 6 | 8 | 4 | 8 | 4 |
| Lift Speed Slow(m/min) | 2 | 1 | 3 | 1.5 | 2 | 1 | 2 | 1 |
| Number of Falls | 1 | 2 | 1 | 2 | 1 | 2 | 1 | 2 |
| Output Power Fast | 0.25 | 0.4 | 0.4 | 1.6 |
| Output Power Slow | 0.06 | 0.1 | 0.1 | 0.4 |
| Rating Factor Fast | 20 | 20 | 20 | 20 |
| Rating Factor Slow | 40 | 40 | 40 | 40 |
| Net Weight(kg) | 25 | 25 | 27 | 30 | 31 | 33 | 55 | 58 |
Propuct:
This Chain hoist is specially advantageous for lifting work in the
open air and places where no power supply is available.The chain
hoist can be attached to a trolley of any type as a traveling chain
hoist.It is suitable to monorail overhead conveying system,hand
travelling crane and jib crane.
FAQ:
1. Can you customize product ?
Yes, of course. we have a lot of experienced engineers,They can
design products according to customer's requirement.
2. How can you ensure your quality?
Before the delivery, every products will be tested. You are also
warmly welcomed to come to our factory for inspection.
3. What is your delivery & after-sales service?
The delivery is according to order qty . We can answer user's
question and solve their problem in 24 hrs per each day and give
full technical support in time to all of our products.
4.How long will it take you to ship the goods?
It depends on the product you need, but we guarantee to ship it as
soon as possible. Usually in 5-10 days.
5.What kinds of payment you accept?
We usually accept T/T, L/C, etc. If you prefer other payments
terms, please feel free to discuss with us.
