    25m Rock Mine Diamond Core Drilling Rig Geotechnical Drill Rig Explor Drill Rig

    Ask Lasest Price
    Brand Name : RanCheng
    Model Number : RCQ525
    Certification : CE, ISO 9001:2000
    Price : Negotiable
    Payment Terms : T/T, Western Union
    Supply Ability : 100sets per Month
    Delivery Time : 10-15 working days
    • Product Details
    • Company Profile

    25m Rock Mine Diamond Core Drilling Rig Geotechnical Drill Rig Explor Drill Rig

    25m Rock Mine Diamond Core Drilling Rig Geotechnical Drill Rig Explor Drill Rig


    Machine Introduction


    The RCQ525 hydraulic small rotary drilling rig adopts a pressurized drilling method, which can achieve a maximum rotary drilling depth of 25m. Equipped with drilling tools of different specifications, the pile hole diameter range can reach 500-1200mm.


    This small pile driver has high drilling efficiency and can be quickly transferred to the next construction site after the construction is completed. It is flexible, convenient and efficient. It is a pile driving machinery and equipment dedicated to the national high-speed railway construction.


    Technical Parameters


    ModelRCQ525 bore piling rig
    Working modeHydraulic oil cylinder pressure
    Drilling diameterΦ500-Φ1500mm
    drilling depth25m
    Kelly bar diameter315mm
    Dimension11000X2800X3450mm
    Total weight25T
    Power head max output torque120KN.m
    Rotary speed10-50r/min
    Pressurized oil cylinder max pressure100KN
    Pressurized oil cylinder max lifting force100KN
    Pressurized oil cylinder max stroke2500mm
    Main winch max lifting force120KN
    Main winch max lifting speed70m/min
    Wire rope diameter24mm
    Assisting winch max lifting force30KN
    Assiting winch max lifting speed50m/min
    Wire rope diameter12mm
    Mast sidewards inclination±4°
    Mast forwards inclination
    Max working pressure28Mpa
    pilot pressure3.5Mpa
    Travelling speed5km/h
    Max climbing angle30
    Working radius4m
    Diesel engine power150KW ,cummins ,water cooling ,turbo charger ,

    Machine Advantages


    This pie drilling rig Mainly used in soft soil piling, such as the foundation, seaports, Bridges, reservoirs station, and national defence construction and so on, widely used in rotary screw pile ,pile engineering, drilling engineering, geological prospecting, building projects, such as engineering blasting and so on.


    Machine Pictures


    Quality 25m Rock Mine Diamond Core Drilling Rig Geotechnical Drill Rig Explor Drill Rig for sale
