Home Energy Storage Integrated Machine Series Built in Fan IP20 XPF-256100-A RS485 / WiFi

    Buy cheap Home Energy Storage Integrated Machine Series Built in Fan IP20 XPF-256100-A RS485 / WiFi from wholesalers

    Buy cheap Home Energy Storage Integrated Machine Series Built in Fan IP20 XPF-256100-A RS485 / WiFi from wholesalers
    • Buy cheap Home Energy Storage Integrated Machine Series Built in Fan IP20 XPF-256100-A RS485 / WiFi from wholesalers

    Home Energy Storage Integrated Machine Series Built in Fan IP20 XPF-256100-A RS485 / WiFi

    Ask Lasest Price
    Model Number : XPF-256100-A
    Certification : CE、MSDS
    Price : Negotiable
    Payment Terms : L/C,D/A,D/P,T/T
    Supply Ability : 1000 pcs per mouth
    Delivery Time : 5-8 weeks
    • Product Details
    • Company Profile

    Home Energy Storage Integrated Machine Series Built in Fan IP20 XPF-256100-A RS485 / WiFi

    Home Energy Storage Integrated Machine Series Built-in Fan IP20 XPF-256100-A RS485/WiFi



    Product parameter


    ModelXPF - 256100 - A
    Battery Pack Parameters
    Battery Pack Specification25.6V 100Ah
    Nominal Voltage25.6V
    Operating Voltage Range21.6V28.8V
    Rated Energy2.56kWh
    PV Input Parameters
    Maximum PV Open - Circuit Voltage160VDC
    MPPT Voltage Range30128VDC
    Maximum Input Power1600W
    Maximum Charge - Discharge Current50A
    AC Output/Input Parameters
    Input/Output Voltage220240VAC
    Selectable Voltage Range170V280VAC (UPS) / 90V280VAC (APL) / 184V253VAC (VDE)
    Input Current14A
    Output Current17A (Terminal) / 10A (Socket)
    Frequency50Hz/60Hz (Self - adapting)
    Rated Output Power3000W
    General Parameters
    Communication ProtocolRS485/WiFi
    Working Altitude≤2000m
    Cooling MethodBuilt - in Fan
    Installation MethodWall - mounted or Floor - standing
    IP RatingIP20
    Cycle Life≥6000 @ 25°C, 80% DOD
    Operating Temperature055
    Storage Temperature-20~55℃
    Humidity≤80%
    Product Dimensions410×845×195mm
    Packaging Dimensions510×945×315mm
    Product Net Weight45kg
