    DTH Hammer Blast Hole Drill Rigs Crawler Mounted Open Air Split Type

    Ask Lasest Price
    Brand Name : Aoxing
    Model Number : ZGYX-415
    Certification : ISO9001
    Supply Ability : 30 Sets/Month
    • Product Details
    • Company Profile

    DTH Hammer Blast Hole Drill Rigs Crawler Mounted Open Air Split Type

    Crawler Mounted DTH Hammer Blasting Hole Drill Rigs


    Product Description

    ZGYX-415 open-air split-type deep hole drilling machine is another high-performance research and development of mining industry cost-effective rig products. 415 model drilling rig is in a large number of ZGYX-410E drill rig users to use the report, the drilling rig components, hydraulic systems, propulsion beam, rotary head, the whole body to upgrade and optimize. The upgraded drilling rig has the advantages of strong climbing ability, large turning torque and long motor life, and it is suitable for the open mining environment under various conditions.
    ZGYX-415 crawler mounted DTH drilling rig technical figures
    Rig modelZGYX-415
    Diesel engine modelYuchai YCD4R12T-70
    Engine power50 KW
    Drilling depth15-20m
    Drilling diameterΦ90127mm
    Working air pressure0.8-1.45 MPa
    Air consumption7-13 m3/min
    Drilling pipe diameterΦ60,Φ76
    Length of drill pipe3.0m
    One push length3.0m
    Tramming speed2.5km/h
    Climbing ability (Max.)25°
    Ground clearance (Min.)250mm
    Rotation speed0-110 rpm
    Rotation torque1850 N.m
    Propulsion15KN
    Lifting capacity250KN
    Propulsion modeCylinder chain
    Weight4500kg
    Transportation dimension5500x2000x2100mm
