    SICK Gas Analyzers SMC9021 A continuous emission monitoring system

    Ask Lasest Price
    Brand Name : SICK
    Model Number : Gas Analyzers SMC9021 A continuous emission monitoring system
    Certification : CCCI
    Payment Terms : T/T
    Supply Ability : 100
    Delivery Time : 10-15days
    • Product Details
    • Company Profile

    SICK Gas Analyzers SMC9021 A continuous emission monitoring system

    Measured values CO, CO2, NOx, O2, SO2
    Performance-tested measurands CO, CO2, NOx, O2, SO2
    Measurement principles NDIR spectroscopy, electrochemical cell
    Gas flow rate
    10 l/min ... 60 l/min
    Measuring ranges
    CO 0 ... 500 mg/m³ / 0 ... 2,500 mg/m³
    NO 0 ... 500 mg/m³ / 0 ... 2,500 mg/m³
    O2 0 ... 21 Vol.-%
    SO2 0 ... 500 mg/m³ / 0 ... 2,500 mg/m³
    Certified measuring ranges
    CO 0 ... 2,500 mg/m³
    NO 0 ... 2,500 mg/m³
    SO2 0 ... 2,500 mg/m³
    Response time (t90) ≤ 15 s
    Accuracy
    ≤ ± 1 %
    Of measuring range full scale
    Sensitivity drift
    ≤ ± 1 %: of measuring range full scale per week
    Zero point drift
    ≤ ± 1 %: of measuring range full scale per week
    Reference point drift
    ≤ ± 1 %: of measuring range full scale per week
    Detection limit
    ≤ 1 %
    Resolution
    ≤ 1 %
    Process temperature
    ≤ +300 °C
    Process pressure
    –100 hPa ... 100 hPa
    Relative
    Ambient temperature
    +5 °C ... +35 °C
    Storage temperature
    –20 °C ... +70 °C
    Ambient pressure
    900 hPa ... 1,100 hPa
    Enclosure rating
    IP40
    Analog outputs 4 outputs:
    4 ... 20 mA
    Analog inputs Optional 2 inputs possible
    Digital outputs Optional 4 outputs possible
    Digital inputs Optional 4 inputs possible
    Dimensions (W x H x D)
    800 mm x 2,100 mm x 800 mm
    Weight
    ≤ 300 kg
    Energy supply
    Voltage 220 V AC
    Frequency 50 Hz
    Power consumption ≤ 2,000 VA
    Auxiliaries
    Instrument air: ≥ 4 bar ≤ 100 l/min
    During backflushing
    Sample gas connections
    Sample gas inlet 8 mm diameter
    Exhaust gas outlet 14 mm diameter
    Auxiliary gas connections
    Instrument air DN 6/8
    Corrective functions Manual or automated adjustment with test gases
    System components

    Gas sampling unit

    Sample gas line

    Analyzer cabinet

    Connection unit

    Integrated components

    Temperature sensor

    Pressure sensor

    Humidity sensor

    Flow sensor

    SMC900
