Product Description:
HBT-WPB210t HDMI HDBaseT Extender Wall Plate - 4K@60Hz over Single
CAT6 up to 100m
Elevate professional AV installations with the HBT-WPB210t
Wallplate HDBaseT Extender, a premium solution for extending
4K@60Hz HDR video, audio, and control signals up to 100m via a
single CAT6/7 cable. Designed for seamless integration in
commercial, residential, and industrial environments, this HDMI
over HDBaseT wall plate extender delivers uncompromised 18Gbps
bandwidth, zero latency, and enterprise-grade reliability.
Features:
Extended Transmission Distance: Delivers HDMI signals up to 70 meters at 1080p and up to 40 meters
at 4K UHD over a single Cat cable, simplifying installations and
reducing cable clutter.
4K/UHD Capability: Supports ultra-high-definition video, future-proofing your AV setup
for evolving technology standards.
Bi-Directional IR Control: Enables seamless control of source and display devices from either
end of the connection, enhancing user convenience.
Power over HDBaseT (PoH): Requires only a single power supply at either the transmitter or
receiver end, streamlining installation and reducing the need for
multiple power sources
HDCP Compliance: Ensures secure transmission of protected content, maintaining
compatibility with the latest HDMI standards.
Technical Parameters:
| Power Supply | DC 12V 2A |
| Compatibility | HDMI 2.0 |
| Transmission Distance | 4K*2K@60Hz4:2:0 extend 70m by Cat6 ,1080P extend 100m by Cat6 |
| Video Resolution | 4K@60Hz |
| HDMI Resolution | 1080P/1080i/720P/576P |
| Power Adapter Format | Input AC (50Hz-60Hz) 100-240V |
| Video Interface | HDMI |
| HDCP Version | HDCP2.2 |
| Product Name | 4K HDBaseT Extender |
Applications:
Winlink WL-HB100S HDMI HDBaseT Extender is engineered for
professional AV systems, delivering 4K@60Hz (4:4:4 chroma) ultra-HD
transmission over CAT6/7 cables up to 100m. Integrated with USB KVM
control, bi-directional IR/RS-232 signals, and PoC (Power over
Cable), it excels in:
1️⃣ Corporate Meetings: Multi-screen 4K mirroring & remote device
management.
2️⃣ Medical Imaging: 4K endoscopy/ultrasound video transmission
with medical peripheral connectivity.
3️⃣ Education/Broadcast: Low-latency 4K content distribution in
classrooms/studios.
4️⃣ Security Surveillance: Long-distance 4K camera feeds & PTZ
control.
5️⃣ Digital Signage: Centralized 4K ad management in
malls/airports, HDCP 2.2 compliant.
