IFM PA3024 Pressure transmitter with ceramic measuring cell in stock

IFM PA3024 Pressure transmitter with ceramic measuring cell in stock

IFM PA3024 Pressure transmitter with ceramic measuring cell in stock

• Precise linear 4...20 mA output signal
• High repeatability and low linearity error
• With long-term stability thanks to high overload protection
• Robust stainless steel housing for use in harsh industrial environments
• Wide operating temperature range
•

• Product characteristics

  Number of inputs and outputs	Number of analogue outputs: 1
  Measuring range	0...10 bar 0...145 psi 0...1000 kPa 0...1 MPa
  Process connection	threaded connection G 1/4 internal thread

  Application

  Special feature	Gold-plated contacts
  Application	for industrial applications
  Media	liquids and gases
  Medium temperature[°C]	-25...90; (on request: -40...90 °C)
  Min. bursting pressure	150 bar 2175 psi 15 MPa
  Pressure rating	75 bar 1088 psi 7.5 MPa
  Type of pressure	relative pressure

  Electrical data

  Operating voltage[V]	9.6...32 DC
  Min. insulation resistance[MΩ]	100; (500 V DC)
  Protection class	III
  Reverse polarity protection	yes

  Inputs / outputs

  Number of inputs and outputs

  Number of analogue outputs: 1

  Outputs

  Total number of outputs	1
  Output signal	analogue signal
  Number of analogue outputs	1
  Analogue current output[mA]	4...20
  Max. load[Ω]	720; (Ub = 24 V; (Ub - 9,6 V) / 20 mA)
  Overload protection	yes

  Measuring/setting range

  Measuring range

  0...10 bar 0...145 psi 0...1000 kPa 0...1 MPa

  Accuracy / deviations

  Repeatability[% of the span]	< 0,1; (with temperature fluctuations < 10 K)
  Characteristics deviation[% of the span]	< ± 0,25 (BFSL) / < ± 0,5 (LS); (BFSL = Best Fit Straight Line; LS = limit value setting)
  Long-term stability[% of the span]	< ± 0,05; (per 6 months)
  Temperature coefficient zero point[% of the span / 10 K]	0,1; (0...80 °C)
  Temperature coefficient span[% of the span / 10 K]	0,2; (0...80 °C)

  •We can shipping all over the world.via DHL,UPS,Fedex and EMS, the packaging is very safe and strong. if you have any special needs,please notify me.

  •It will take 3 to 7days to reach in your hands.China Post delivery schedule will be in 20-45 days. If you can't wait, please choose other express.
