    Webcam Aging Rack Remote Computer Monitoring Camera Burn In Test Equipment

    Ask Lasest Price
    Brand Name : CPET
    Model Number : CP-SX02
    Price : 8500dollars/set
    Payment Terms : L/C
    Supply Ability : 30sets/month
    Delivery Time : 35 work days
    • Product Details
    • Company Profile

    Webcam Aging Rack Remote Computer Monitoring Camera Burn In Test Equipment

    Webcam Aging Rack Remote Computer Monitoring Camera Burn-In Test Equipment


    Performance parameters
    1Introduction to the appearance structure of the aging trolley:
    ACar size (mm) :L2050mm*W880mm*H1900mm double-sided door
    BProduct area clearance size:L1650*W600mm
    CNumber of car layers:6
    DHeight of truck:170mm
    ELoad area heat dissipation mode:Top turbine exhaust fan up-row
    FInterlayer insulation and anti-static mode:Epoxy insulating board with heat dissipation holes on the surface
    GTruck structure form:Product area adopts front and rear double doors, easy to load and unload products on both sides
    2Description of power module configuration, measured power, and aging quantity:
    ADc power supply configuration:A 12V/29A DC power supply is configured for each layer to supply DC power below 12V/1.0A for each product bit
    BNumber of aging products in the whole container:120 sets of products below 12V/1A
    CConnection mode:The DC input terminal is configured with a DC bus (5521), reserved network ports in each bit, switches in each layer, and a master switch on top. The switch is installed at the top
    DProduct area temperature control accuracy:Normal temperature+10℃~55℃(±5℃)
    EProduct area temperature control principle:Low temperature heating, over temperature exhaust
