BT201 dual-mode 5.0 Bluetooth receiving module for TF card U disk

    Buy cheap BT201 dual-mode 5.0 Bluetooth receiving module for TF card U disk from wholesalers

    Buy cheap BT201 dual-mode 5.0 Bluetooth receiving module for TF card U disk from wholesalers
    • Buy cheap BT201 dual-mode 5.0 Bluetooth receiving module for TF card U disk from wholesalers
    • Buy cheap BT201 dual-mode 5.0 Bluetooth receiving module for TF card U disk from wholesalers
    • Buy cheap BT201 dual-mode 5.0 Bluetooth receiving module for TF card U disk from wholesalers

    BT201 dual-mode 5.0 Bluetooth receiving module for TF card U disk

    Ask Lasest Price
    Price : Email us for details
    Payment Terms : Paypal,TT,Western Union
    • Product Details
    • Company Profile

    BT201 dual-mode 5.0 Bluetooth receiving module for TF card U disk


    CEEH178 Transformer SMD Type CEEH Series


    BT201
    Length (mm):8
    Width (mm):3
    Height (mm):0.5
    Applications:audio data module

    Feature:
    1. Built-in 3W amplifier
    2. Support DC 5V input
    3. Industrial design stable and efficient
    4. Support BLE/SPP data transmission
    5. MP3 15meter lossless data transmission
    6. Support UART
    7. Support button adjust control
    8. Support U-disk(Max 128G)
    9. Support TF card(Max 128G)

    Parameter:

    1. Model:BT-201
    2. Work voltage:DC 3.3V-5V
    3. Quiescent current:20mA
    4. Support file format:MP3/WAV/WMA/FLAC/AAC/APE
    5. UART interface:TTL level
    6. Baud rate:Adjustable
    7. Output power:4ohm 3W
    8. Operating Temperature:-20℃~85℃
    9. Operating Humidity:5%~95%RH
    10.Module Size:60*40*8mm

    Button description:

    1. PREV/V-: Short press to select previous music.Long press to decrease volume.
    2. NEXT/V+: Short press to select next music.Long press to increase volume.
    3. MODE: Switch audio input type from Bluetooth,U-disk,TF card.
    4. PP: Play or Pause.

    Function:

    1. Automatically generate Bluetooth MAC address.
    2. Support MP3/WAV/WMA/FLAC/AAC/APE file format decoding.
    3. Maximum support 128G U-disk and TF card.
    4. Support breakpoint memory and play memory.
    5. Support Bluetooth audio input.
    6. Support play/pause,switch previous/next music.
    7. Support phone call function.User can set cancel call.
    8. Support Answer/Hang up/Call back/Refuse for phone call.
    9. Support Bluetooth 5.0.
    10.Support HFP/A2DP/AVRCP/HSP/GAVDP/IOP/SPP/BLE.
    11.Maximum communication distance about 15meter.
    12.Frequency range 2.4GHz~2.480GHz.Class2 4dbM.

    UART description:

    1. Baud rate:115200bps(User can set by command)
    2. Data bit:8bit
    3. Stop bit:1bit
    4. Check Digit:None
    5. Control flow:None
    6. Control command format: AT+<CMD>[<param>]rn
    7. Return data format: <IND>[<param>]rn
    8. AT+:The start of a control command.
    9. <CMD>:Specific control command.
    10.[<param>]:The parameter of CMD if need.
    11.rn:Enter and Wrap.
    12.<IND>:The start of return data.
