    OPTO-EDU M30.5820 Full Auto Microscope Slide Scanner 60/120/240/480 Slides

    Ask Lasest Price
    Brand Name : CNOEC, OPTO-EDU
    Model Number : M30.5820
    Certification : CE, Rohs
    Price : FOB $1~1000, Depend on Order Quantity
    Payment Terms : T/T, West Union, Paypal
    Supply Ability : 5000 pcs/ Month
    Delivery Time : 5~20 Days
    • Product Details
    • Company Profile

    OPTO-EDU M30.5820 Full Auto Microscope Slide Scanner 60/120/240/480 Slides

    • 60/120/240/480 Standard pathology slides (75*25mm) Capacity
    • High Quality Plan Apochromatic Objective Lens APO20x N.A. 0.8, APO40x NA. 0.45
    • 5.0M Scientific Research-grade Large-area CMOS Digital Camera
    • Scanning Resolution 20x Scan ≤0.24um/pixel, 40x Scan ≤0.12um/pixel
    • Scanning Speed 15x15mm Area 20x Scan <35s, 40x Scan <50s

    Ultra-high Quality

    High-quality flat-field apochromatic object sharp scientific research-grade ultra-high-speed area array camera (Patented face scanning technology) Independently developed military-grade high-brightness full-range LED light source

    High-speed and high-quality presentation of tissue and cell structure morphology


    High-speed Scanning

    15.00mmx15.00mm scanning range

    20x magnification mode, ≤35 seconds

    40x magnification mode, ≤50 seconds


    Improved Efficiency

    It can provide bright field fast scanning, and can also realize fluorescence, phase contrast, and polarization scanning by upgrading the reef equipment to meet different scientific research needs


    Slide Protection

    Advanced machine vision technology

    Adaptive slide travel recognition

    Automatically monitor and prompt slide positioning and system abnormalities

    Dual Screen Dual Control

    The machine body is integrated with a touch screen display, which can independently control slide scanning and slide browsing, without the need for external auxiliary equipment, realizing dual-screen dual control of the equipment


    Ultra-high Stability

    Technology accumulation creates a record of continuous scanning of 5,000 sheets without error

    Single scan success rate is greater than 95%


    Flexible Throughput

    60 pieces/120 pieces/240 pieces/480 pieces of various flux specifications are flexible to choose from to meet different construction needs

    Support original machine flux upgrade to calmly face future development


    One-click Sharing

    The scanned digital slides can be shared with any user by generating a QR code with one click. Users can browse and edit the slides through smart terminals, which is convenient and fast.

    slide Loading Recognition Function

    Automatically skip the loading point without slides during continuous scanning


    slide Label Recognition Function

    Automatically recognize the symbol, barcode or QR code information in the slide label


    Organization Outline Recognition Function

    Intelligently recognize the outline of the tissue area in the slide, and skip the non-organization area during the scanning process


    slide Stroke Recognition Function

    Using machine vision technology, it can automatically monitor and prompt the abnormality of the slide during the scanning process to avoid fragmentation and card

    Tissue or cell quantitative analysis software

    Mitophagy technology software

    Immunohistochemistry quantitative analysis software

    Digital slide management and browsing software

    Remote consultation software

    M30.5820 High Throughput Digital slide Scanning Analysis System Specification
    Slide Capacity60pcs/120pcs/240pcs/480pcs standard pathology slides (75*25mm)
    ObjectiveAPO 20x N.A.0.8 high quality plan apochromatic objective lens
    APO 40x N.A.0.45 high quality plan apochromatic objective lens
    Camera5.0M Scientific research-grade large-area CMOS digital camera
    Scanning MethodHigh-speed continuous area scanning
    Scanning Speed15x15mm scanning area:
    -20x scan, <35 seconds
    -40x scan, <50 seconds
    Scanning Resolution20x scan ≤ 0.24um/pixel
    40x scan ≤ 0.12um/pixel
    Scanning ModeFast, Accurate, 3D, Fusion mode
    Repeat Position AccuracyX, Y axis ≤ 40nm, Z axis ≤ 25nm
    Multi-layer Scanning FunctionZ-axis automatic focusing, multi-layer scanning, each layer image can be browsed and saved
    Fusion Scanning FunctionApplying depth of field fusion technology to obtain ultra-depth scanning images
    Intelligent RecognitionAutomatic identification of slide type: HE/IHC/Cyto
    Automatic identification of label symbols, barcodes and QR codes
    SoftwareScan Software: iScanneX, Browser Software: iViewer
    Product Size896mmx635.5mmx715mm

    It provides solutions for a variety of applied research and can be widely used in scientific research, teaching, biochips, cancer and tumor research, toxicology and drug safety evaluation, forensic pathology and other fields.
