1. Product Introduction
The 6-channel drone jammer is a high-efficiency device specially
designed for small-to-medium-sized protection scenarios in the
anti-drone industry. With 6 independent jamming channels, it
achieves precise frequency coverage from 400MHz to 1200MHz, and
each channel delivers a stable output power of 47dBm (50W). It can
strongly block the communication link between drones and remote
controllers, cut off navigation and image transmission signals,
effectively prevent unauthorized drone intrusions, and ensure
short-to-medium-range airspace security.
Adopting a wide-voltage DC power supply design (+12V～+28V), the
device supports external power supply or optional battery power,
flexibly adapting to both fixed deployment (e.g., corporate
campuses, cultural heritage protection areas) and mobile protection
(e.g., small-to-medium-sized concerts, outdoor exhibitions)
scenarios. With a low power consumption of ≤600W and an energy
efficiency of ≥50%, it reduces energy consumption while ensuring
jamming performance, making it suitable for long-term standby and
continuous operation.
In terms of structure, the device has a compact size of only
45cm*37cm*22cm and a weight of ≤14kg, which can be easily carried
by a single person, solving the problem of "difficult deployment
due to heaviness" of traditional jammers. Equipped with
omnidirectional FRP (Fiberglass Reinforced Plastic) spring antennas
(gain: 3±1dBi, power capacity: 100W), it provides non-dead-angle
signal coverage, further improving jamming stability and effective
range. Currently, it is widely used in anti-drone scenarios such as
security for small-to-medium-sized events, airspace control in
scenic areas, and protection for corporate factory areas.
2. Core Technical Specification Table
| No. | Category | Specific Item | Technical Parameters |
|---|
| 1 | Jamming Channels | Channel 1 | Operating Frequency: 400MHz～500MHz; Output Power: 47dBm (50W) |
| 1 | Jamming Channels | Channel 2 | Operating Frequency: 500MHz～600MHz; Output Power: 47dBm (50W) |
| 1 | Jamming Channels | Channel 3 | Operating Frequency: 600MHz～730MHz; Output Power: 47dBm (50W) |
| 1 | Jamming Channels | Channel 4 | Operating Frequency: 730MHz～910MHz; Output Power: 47dBm (50W) |
| 1 | Jamming Channels | Channel 5 | Operating Frequency: 910MHz～1100MHz; Output Power: 47dBm (50W) |
| 1 | Jamming Channels | Channel 6 | Operating Frequency: 1100MHz～1200MHz; Output Power: 47dBm (50W) |
| 2 | Power Supply Parameters | Supply Voltage | DC: +12V～+28V (supports battery power, battery optional) |
| 3 | Energy Consumption Parameters | Max Power Consumption | ≤600W |
| 3 | Energy Consumption Parameters | Energy Efficiency | ≥50% |
| 4 | Structural Parameters | Device Dimension | 45cm * 37cm * 22cm |
| 4 | Structural Parameters | Device Weight | ≤14kg |
| 5 | Interface Configuration | Power Interface | Aviation Socket WS20-2 |
| 5 | Interface Configuration | RF Interface | N-J Type, Impedance 50Ω |
| 6 | Antenna Parameters | Antenna Type | Omnidirectional FRP Spring Antenna |
| 6 | Antenna Parameters | Antenna Gain | 3±1dBi |
| 6 | Antenna Parameters | Antenna Power Capacity | 100W |
| 7 | Standard Accessories | Accessory List | Wired Power Box (1PCS), Strong Magnetic Screws (6PCS), Adapters
(6PCS) |
3. Frequently Asked Questions
Q1: What are the core differences between this 6-channel jammer and
8-channel models?
A1: The core differences lie in frequency coverage range,
size-weight, and power consumption: ① In terms of frequency, the
6-channel model covers 400MHz-1200MHz (focusing on frequency bands
commonly used by mainstream drones), while 8-channel models cover
220MHz-1500MHz (wider coverage); ② In terms of size and weight, the
6-channel model (45*37*22cm, ≤14kg) is more lightweight, while
8-channel models (50*45*27cm, ≤23kg) are heavier; ③ In terms of
power consumption, the 6-channel model is ≤600W, while 8-channel
models are ≤785W. The 6-channel model is more suitable for mobile
deployment in small-to-medium-sized scenarios; if full-frequency
protection is required, 8-channel models can be selected.
Q2: The device weighs ≤14kg. Is additional equipment needed for
mobile deployment?
A2: No additional equipment is required. The device weighs only
14kg and can be directly carried by one person. With the strong
magnetic screws included in the accessories, it can be quickly
fixed on vehicle-mounted platforms, the top of security booths,
etc. The whole process from unboxing to activation takes only 5-10
minutes, meeting the "rapid response" demand of temporary security
scenarios.
Q3: Can the 400MHz-1200MHz frequency band cover mainstream consumer
drones?
A3: Yes. Currently, more than 90% of consumer drones on the market
(brands such as DJI, Xiaomi) use communication/navigation frequency
bands (433MHz, 868MHz, 915MHz, 1.2GHz, etc.) that fall within the
400MHz-1200MHz range, and the device can effectively jam such
drones. If coverage of special frequency bands above 1200MHz is
needed, please contact the manufacturer for customized expansion.
Q4: What is the approximate battery life in battery-powered mode?
A4: Battery life depends on battery capacity. Taking a common
100Ah/24V lithium battery as an example, the fully charged battery
can support the device for about 3-4 hours of continuous operation
(calculated based on maximum power consumption of 600W). To extend
battery life, backup batteries or external portable power supplies
can be used to meet the demand for long-term outdoor protection.
Q5: The RF interface is equipped with 6 adapters. Do they need to
be connected to antennas corresponding to each channel?
A5: Yes. Each adapter needs to be connected to an antenna
corresponding to one jamming channel to ensure independent signal
output of each channel without interference. The adapters are
designed with standard N-J type compatibility and can be plugged
and unplugged without additional tools, allowing even
non-professionals to quickly complete antenna connection.
