X-Ray Solution YS-X5600,Microfocus X-Ray Inspection System Manufacturer

1.Application:

2.Functions and Features:

3.Application Advantage:

• Miniaturized equipment, easy to install and operate
• Applicable to Chip, BGA/CSP, Wafer, SOP/QFN, SMT and PTU packaging, Sensors and other fields products inspection.
• High resolution design to get the best image in a very short time.
• Infrared automatic navigation and positioning function can select the shooting location quickly.
• CNC inspection mode which can quickly and automatically inspect multi-point array.
• Inclined multi-angle inspection makes it easier to inspect sample defects.
• Simple softwareoperation, low operating costs
• Long lifespan

4.Automatic Void Ratio Calculation

Enhanced BGA inspection function

YS-X5600 can quickly select and mark a single solder ball, or select the solder balls to be inspected by matrix box ; it can manually or automatically identify BGA solder balls and complete the inspection. Follow the system guidelines to easily complete the inspection process and ensure accurate and reliable inspection results.

5.X-Ray Working Principle

6.CNC Programming

• Simply click the mouse and you can write programs.
• Object table moves along X, Y direction for positioning; X-ray tube move along Z direction for positioning.
• Voltage and current set by software.
• Image settings: brightness, contrast, auto gain and exposure
• Users can change the pause time for program conversion.
• Anti-collision system can maximize the tilt and observation of the workpieces.
• Automatic analysis on diameter, proportion of cavity, area and roundness of BGA.
