Rustproof Multi Media Water Filter Systems , 125m3/H Sand Filter Water Treatment

multi media water filter systems

Media filter (vertical)

Introduction

The media filter can use a single media or multiple media according to different needs. The main media of single-media filters are generally quartz sand, manganese sand, and activated carbon. Multi-layer media filters are also called multi-media filters. Its filter media is composed of more than one filter media, generally quartz sand, anthracite and other contact medium.

The quartz sand filter is mainly used to reduce the suspended substance and turbidity indicators of the filtered water. The activated carbon filter is mainly used to reduce the content of organic matter and oxides (residual chlorine). The manganese sand in the manganese sand filter mainly plays a catalytic role, and cooperates with the oxidation of dissolved oxygen in the water to remove iron and manganese ions from the water.

Multi-media multi-filter usually refers to a filter composed of anthracite and quartz sand, which is used to reduce the suspended substance and turbidity indicators of the filtered water.

Although the aforementioned filter materials are different, the structure of the filter body is basically similar.

Application

1. It is suitable for water plants in rural towns or industrial and mining enterprises that use all kinds of rivers, lakes, reservoirs and other water source with raw water suspended substance less than 20mg/l. Can be used as the main water purification device.

2. For lake water sources with low turbidity and seasonal algae, it has its special adaptability.

3. Pre-treatment equipment for high-purity water, beverage industry water, boiler water and other pre-water treatment.

4. Used in various industrial circulating water systems, which can effectively and greatly improve the quality of circulating water.

5. Used in the middle water system, using the sewage plant as the water source, as a treatment equipment for purifying reusing water.

Equipment description:

1. Two control modes of manual and automatic can be realized. The trigger conditions of automatic mode include: liquid level, flow, pressure difference, turbidity, running time, etc.

2. There are many types of upper and lower water distributors, which are designed according to specific operating conditions.

3. The type of filter material, the number of filling species, and the filling height are determined according to the water production requirements, and the height of the filter cylinder is determined according to the filter material conditions.

4. The value of the filtration rate should be determined according to the water quality conditions and the characteristics of the filter material.

Design parameters ( take multi-media filter as an example)

List of corollary equipment (take multi-media filter as an example)

Media filter (horizontal)

Introduction

Horizontal media filters are usually used as fine sand filters or multi-media filters. The fine sand filter is a single medium filter, the medium is generally quartz sand and manganese sand. The multi-media filter is a multi-layer medium filter. Its filter medium is composed of more than one filter medium, generally quartz sand, anthracite and other contact media.

The quartz sand filter is mainly used to reduce the suspended substance and turbidity indexes of filtered water. Multi-media multi-filter usually refers to the filter composed of anthracite and quartz sand to reduce the suspended substance and the turbidity index of filtered water.

Although the above-mentioned filter materials are not the same, the structure of the filter body is basically similar, and can be designed as a horizontal single-layer or multi-layer structure.

Compared with the vertical media filter, the horizontal media filter occupies a small unit area and more water production, which is very suitable for large-scale water treatment projects.

Application

1. It is suitable for water plants in rural towns or industrial and mining enterprises that use all kinds of rivers, lakes, reservoirs and other water source with raw water suspended substance less than 20mg/l. Can be used as the main water purification device.

2. For lake water sources with low turbidity and seasonal algae, it has its special adaptability.

3. Pre-treatment equipment for high-purity water, beverage industry water, boiler water and other pre-water treatment.

4. Used in various industrial circulating water systems, which can effectively and greatly improve the quality of circulating water.

5. Used in the middle water system, using the sewage plant as the water source, as a treatment equipment for purifying reusing water.

Equipment description:

1. Two control modes of manual and automatic can be realized. The trigger conditions of automatic mode include: liquid level, flow, pressure difference, turbidity, running time, etc.

2. There are many types of upper and lower water distributors, which are designed according to specific operating conditions.

3. The type of filter material, the number of filling species, and the filling height are determined according to the water production requirements, and the height of the filter cylinder is determined according to the filter material conditions.

4. The value of the filtration rate should be determined according to the water quality conditions and the characteristics of the filter material.

Design parameters ( take multi-media filter as an example)

List of corollary equipment ( take multi-media filter as an example)
