    High Power Electronics PCB Design PADS Layout Engineering Consulting Services

    PADS Layout Engineering Consulting Services Electronics PCB Design


    Typical data needed for quote:


    BOM with manufactures part numbers
    Centroid data for all machine placed parts
    Gerber files of PCB
    Solder paste gerber file if supplying the bare boards to us
    Testpoint data if ICT needed


    PCB capability:


    Product NameElectronics PCB Design
    TypeRigid
    MaterialFR4, CEM1, CEM3, High Frequency Board,
    Layer1,2,4,6...20Layer
    ShapeRetangular, Round, Slots, Cutouts, Complex, Irregular
    CuttingShear, V-score, Tab-routed
    Board Thickness0.2-4mm, regular 1.6mm
    Copper Thickness0.5-4oz, regular 1oz
    Silk ScreenWhite, Black, etc.
    Silk Screen Min Line Width0.006" or 0.15mm
    Min Trace/Gap0.1mm or 4mils
    Min Drill Hole Diameter0.01",0.25mm or 10mils
    Surface FinishHASL, ENIG, OSP, etc.

    PCB design service:


    1. HDI Designs with micro vias and advanced materials – Via-in-Pad, laser micro vias.
    2. High speed, multi layer digital PCB designs – Bus routing, differential pairs, matched lengths.
    3. PCB Designs for space, military, medical and commercial applications
    4. Extensive RF and analog design experience (printed antennas, guard rings , RF shields…)
    5. Signal integrity issues to meet your digital design needs (tuned traces, diff pairs…)
    6. PCB Layer management for signal integrity and impedance control
    7. DDR2, DDR3, DDR4, SAS and differential pair routing expertise
    8. High density SMT designs (BGA, uBGA, PCI, PCIE, CPCI…)
    9. Flex PCB designs of all types
    10. Low level analog PCB designs for metering
    11. Ultra low EMI designs for MRI applications
    12. Complete assembly drawings
    13. In-Circuit Test data generation (ICT)
    14. Drill, panel and cutout drawings designed
    15. Professional fabrication documents created
    16. Autorouting for dense PCB designs



    Expert PCB Assembly services for Military, space, medical, automotive, commercial and ect:


    Shenzhen Yideyi Technology Co., Ltd is an industry leader in high quality PCB Design and turnkey electronic engineering offering the very best service at competitive prices.
