    Servo 4 Rows Automatic Aluminum Radiator Core Builder HMI Operation

    Aluminum Radiator Core Builder Machine


    Application of Aluminum Radiator Core Builder Machine

    The radiator core builder assembles together the flat tubes, fins, headers, and side plates, and assemble them into a radiator core.


    Main features:

    The radiator core builder machine is used for assembling radiator cores. The aluminum radiator core builder machine has the advantages of stable and reliable working performance, easy operation, low noise, accurate positioning of flat tube center, and even distribution of fins. The assembled radiator core has a high assembling accuracy and a good appearance, which ensures a better brazing effect in the brazing furnace.The aluminum radiator core builder machine is mainly comprised of header mold, side plate positioning block, core clamping mechanism, flat tube silo, flat tube distribution mechanism, comb teeth mechanism, driving mechanism, work table, work table up-down mechanism, and electrical control system.

    Technical Parameters of Aluminum Radiators

    radiator fin height: 8.03mm

    core diagonal line tolerance:±1mm;

    Core height: ±1mm, core width: ±1.5mm;

    Distance between fin end and header plate: 2±1mm (could be adjusted through the positioning block).

    equipment mechanical movement time: 55s

    According to the customer’s requirement, the assembly table is preserved with the aluminum fixture hole.

    Safety device: photoelectric light curtain to protect the safety of the operator.

    equipment color

    Equipment body: industrial gray; dangerous area: light yellow.


    Technical Parameters of Aluminum Radiator Core Builder Machine

    Core DimensionCore height direction350-780mm
    Core width direction200-680mm
    Flat Tube Layers1 layer/2layers
    Tube Laying ModeDouble working position
    Flat Tube Flaring ModeAutomatic /Manual
    Fin Laying ModeBy fin tray /Manual
    Production CapacityAround 40sets/hour
    Drive modeServo and Pneumatic
    Overall Dimension2500*2300*1800mm
    Weight2800kg

    Picture of Radiator Core Builder Machine we make:
