Paper Napkin Printing Machine For Sale With Six Colors Printing
From China
Application
This ACE-TNM-6C Paper Napkin Printing Machine For Sale With Six
Colors Printing From China is mainly used to for production of high
quality color printing on napkins. It is with high resolution and
register tolerance. It can automatically fold, emboss, print, cut
and count 1/4 fold table napkins, cocktail napkin, restaurant
napkins, beverage napkin, lunchen napkin, 1/6 fold tallfold
dispenser napkin, wallet tissue and MG paper napkins etc. The
mainly function of this machine is to make multi colors printed
high resolution high quality printing 1 colors, 2 colors, 3 colors,
4 four colors up to eight colors.
Advantage:
1 Best quality printing napkin machine in China now.
2 High resolution printing machine.
3 With six colors printing.
4 With auto web tension system
5 With auto edge guiding system
6- Color register tolerance: ±0.1mm.
Technical parameters as below
Italy Design Automatic High Speed six ColorS Printing Paper Napkin Machine
| Model | ACE-TNM-6C the best quality paper napkin printing machine with six
colors printing in China |
| Output type | 1 layer, with 2 lines output. |
| Folding speed | 200 m/min, about 400-700 piece/min, depending on the paper quality
and napkin size. |
| Raw paper | 13-20g/m2 2-ply, 20-45g/m2 1-ply, wooden pulp paper or others. Other sizes please specify. |
| Jumbo roll size | ≤ (200-460)mm x Φ1200mm (Depending on your napkin size,customized) |
| Napkin unfolded size | 200mm x 200mm to 460mm x 460mm or Customized. |
| Napkin folded size | 100mm x 100mm to 230mm x 230mm One size is fixed. One napkin size is adjustable, decided by the paper roll width. |
| Folding type | Mechanical fold with band saw cutting; 1/4 fold; Vacuum folding and other folding types available. |
| Folding unit | With or without folding fingers. |
| Embossing unit | 1- Steel to paper(wool), Male to female. (Steel to steel is
available.) 2- Embossing pattern can be any LOGO, brand name, flowers etc. 3- Embossing pattern can be customized by client or recommended by
us 4- Controlled by screws, mechanical pressing type. Cylinder type is optional. |
| Printing unit | 1- Flexo printing type. 2- Printing colors customized up to 8 colors. Color register tolerance: ± 0.1mm. 3- Printing Logo is changeable. You just need to change the Printing
Rubber only. 4- Anilox printing roll. 5- Printing roll is adjustable. 6- Ink printing system to be negotiated. |
| Tension control | Speedless Tension control unit to fit the machine for paper of
different quaity and different gsm. With automatic web guiding system. With automatic web tension control system. |
| Calendar unit | Make the napkin softer. |
| Counting | Automatic counting unit |
| Emergent stop | Emergent stop unit to inspect any paper breaks, paper jams. |
| Paper feeding | Synchronizer for feeding paper |
| Power | 10Kw depends on requiremetns (3-phase AC380V 50Hz or customized) |
| Machine size | 7x2x3m |
| Weight | 4000KG |
| Videos and photos available. |
C. Printing Section (advanced design.)
1. This 6 colors paper napkin printing machine is With 6 colors
flexo-graphic printer section. (High quality printing)
2. With ceramic anilox printing rollers.
3. Printing unit with driven by timing belts to make printing more
precise.
4. Simple and easy adjustment of horizontal and longitudinal
registration by turning hand wheel.
5. Both sides of Anilox roll & Rubber roll with buffer for
anti-spill cover to stop the ink spilling out of the ink tank and
spraying somewhere.
6. The printer is equipped with covers on the in tank to prevent
the inks spilling out of the ink tanks.
7. With printing ink reservoir for reserve dropping ink and avoid
ink dropping on machine or place to keep environment clean.
8. Casting iron forming foundation. Floor-standing thickened
Wallboard structure (complete plate) to ensure high speed stable
running no vibration.
9. With one set of heating device (Dryer) for heating the napkin to
make the printing LOGO dry fast.
Configuration:
| Bearings | NSK |
| PLC | Siemens |
| Inverter | Siemens |
| Touch screen | Siemens |
| Auto web guide | Italy Best |
| Auto tension system | Like |
| Steel | High Speed steel |
| Anilox | Ceramix |
FAQ
Q: Are you trading company or manufacturer
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is
60-90 days if the goods are not in stock, it is according to
quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay
the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30%
T/T in advance ,balance before shipment.
Products made by this Napkin Printing Machine With Best Quality Printing On Napkins From
China for reference.:
