    Digital Led Trig Ger Delay Cycle Timer Control Switch Relay Module Micro Usb 5v

    Ask Lasest Price
    Brand Name : DZ
    Model Number : Digital LED Trig ger Delay Cycle Timer
    Certification : ISO9001 | ISO14001 | CE | ROHS
    Price : 10 - 309 Pieces = $1.73, 310 - 649 Pieces = $1.57, 650 - 6499 Pieces = $1.539, ≥ 6500 Pieces = $1.48
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 18600 Pieces Per Month Digital LED Trig ger Delay Cycle Timer
    Delivery Time : 1-10T - 7Days, 11-25T - 10Days, 26-100 - 10Days, > 100-To be negotiated
    • Product Details
    • Company Profile

    Digital Led Trig Ger Delay Cycle Timer Control Switch Relay Module Micro Usb 5v

    Digital LED Trig Ger Delay Cycle Timer Control Switch Relay Module Mi Cro USB 5V

    # Digital LED Trig ger Delay Cycle Timer Properties

    # Digital LED Trig ger Delay Cycle Timer Highlights:
    1. Wide voltage power supply (6 ~ 30V), supports mi croUSB 5.0V power supply, easy to use;
    2. The interface is clear and simple, powerful, easy to understand, meet almost all your needs;
    3. The emergency stop function ("STOP" key);With reverse polarity protection, reverse polarity will not burn the product.
    4. Increase the sleep mode, if this mode is enabled, without any operation within 5 minutes, then automatically turn off the monitor, any key wake-up;
    5. You can set a different OP, CL, LOP parameters, which are independent of each other, and are automatically saved;
    6. After the module is powered down, all parameter settings are not lost.


    # Digital LED Trig ger Delay Cycle Timer Product parameters:
    1: Operating voltage: 6--30V, support mi croUSB 5.0V power supply
    2: Trig ger Source: Active-high (3.0V-24V), have optocoupler isolation, can improve the system's anti-jamming capability (customers can also shorting common ground).
    3: Output capability: You can control the DC 30VDC 5A or 220VAC 5A device.
    4: Quiescent Current: 20mA; Operating Current: 50mA
    5: life: more than 10 million times; Working temperature: -40-85 ℃;
    6: with optocoupler isolation, enhanced anti-jamming capability, industrial grade board.


    # Digital LED Trig ger Delay Cycle Timer Special Note:
    The relay outputs are passive contact, just a switch.
