    NC Rotary Cut Off Machine With Helical Knife And Computer Control

    Ask Lasest Price
    Brand Name : AODONG
    Model Number : AODONG-09
    Certification : ISO 9001
    Price : 1000-3000 usd
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 35 sets per month
    Delivery Time : 25 days
    • Product Details
    • Company Profile

    NC Rotary Cut Off Machine With Helical Knife And Computer Control

    NC Rotary Cut-Off Machine With Helical Knife And Computer Control


    Max Effective Width1100~2200mm
    Max Paper Roll Diameter1500mm
    Max Paper Roll Weight3000kg
    Corrugating RollerΦ280~405mm, 48CrMo alloy steel, hardness HRC58°-60°
    Min Slitting Width150mm
    Cutting Length500~9999mm
    Design Speed100~200m/min
    Heating MethodSteam Heating
    Economic Working Speed80~160m/min

    1) NC Computer-control Rotary Cut-off computer controlled AC servo controller, drive inverter motor work to achieve high-precision cutting.

    2) Orders with real-time input, edit, modify, save, real-time monitoring (paper speed, cut length, remaining length, production process, etc. parameters), change order (serial change order, mandatory change order, priority input), production statistics, remaining orders, warning etc. functions.

    3) Instantaneous and numerical control cutting length, can amend, add, and cancel at any time.

    4) Knife roller transmit gears adopt high-precision grinded gear, spray lubrication.

    3/5/7-layer Corrugated Cardboard Production Line

    1) WJ-I/II/III 3/5/7-layer Corrugated Cardboard Production Line consists of the following machines, Electrical Shaftless Mill Roll Stand, Single Preheater, Fingerless type Single Facer, Overhead Conveyor Bridge, Duplex Preheater, Duplex Gluer, Double Facer, Lift-down Thin Blade Slitter Scorer, NC Cut-off, Right-angle Conveyor & Stacker, etc.

    2) Kraft Paper Reel to be corrugated and glue by Corn Starch Gum, continuously produce, slit, crease & cut to 3/5-layer Corrugated Cardboard Sheet, and then conveyor, stack and output.

    3) The production line has rational structure design, advanced producing flow, high efficiency, strong batch adjustability, easy operation, etc. good work conditions.

    4) It is the ideal and perfect equipment for corrugated carton box factories.
