R404A 220V 3000KG Flake Ice Maker Machine , Seawater Flake Ice Machine

    Buy cheap R404A 220V 3000KG Flake Ice Maker Machine , Seawater Flake Ice Machine from wholesalers

    Buy cheap R404A 220V 3000KG Flake Ice Maker Machine , Seawater Flake Ice Machine from wholesalers
    • Buy cheap R404A 220V 3000KG Flake Ice Maker Machine , Seawater Flake Ice Machine from wholesalers
    • Buy cheap R404A 220V 3000KG Flake Ice Maker Machine , Seawater Flake Ice Machine from wholesalers
    • Buy cheap R404A 220V 3000KG Flake Ice Maker Machine , Seawater Flake Ice Machine from wholesalers
    • Buy cheap R404A 220V 3000KG Flake Ice Maker Machine , Seawater Flake Ice Machine from wholesalers
    • Buy cheap R404A 220V 3000KG Flake Ice Maker Machine , Seawater Flake Ice Machine from wholesalers
    • Buy cheap R404A 220V 3000KG Flake Ice Maker Machine , Seawater Flake Ice Machine from wholesalers

    R404A 220V 3000KG Flake Ice Maker Machine , Seawater Flake Ice Machine

    Ask Lasest Price
    Brand Name : Yixing ICS
    Certification : ce
    Supply Ability : 100 Set/Sets per Month
    Price : $9,000.00
    • Product Details
    • Company Profile

    R404A 220V 3000KG Flake Ice Maker Machine , Seawater Flake Ice Machine

    Flake Ice Making Machine with Good Compressor China Manufacture

    Product Description

    Flake Ice machine

    Yixing ICS fresh water flake ice machine is widely used in food processing, fruit and vegetables preservation, meat processing, medical research and etc. Seawater flake ice machine is designed for large ocean-going fishing industry which could overcome the corrosion of seawater, pitching and swing problems of vessels. Flake ice is a kind of irregular ice with size about 40*40 mm and
    thickness around 1-2 mm. The thin ice can be directly used for stirring and mixing refrigerated materials. Besides, flake ice has no acute edges and corners so it will not damage the surface of cooled object. With large contact area and fast cooling speed, flake ice can realize high efficiency cooling effects.

    Flake Ice Machine Evaporator

    The internal structure of the evaporator is specially designed to improve heat-exchange efficiency and to keep the loop unblocked with special processing technology. The internally scrapping ice making mode has been adopted, which reduces the loss of the energy and avoids leakage the refrigerant.
    Specification of all types of Flake Ice Machine Yixing ICS Produces
    Model
    Daily Capacity
    Electricity Consumption
    Install Power
    Operating Weight
    Dimention
    BYF-05
    0.5T
    2.56kw
    2.2kw
    208kg
    1200*740*590mm
    BYF-08
    0.8T
    4.43kw
    2.8kw
    235kg
    1200*740*650mm
    BYF-10
    1T
    5.16kw
    4.2kw
    380kg
    1200*740*780mm
    BYF-15
    1.5T
    7.72kw
    5kw
    450kg
    1560*1200*880mm
    BYF-20
    2T
    11.17kw
    6.5kw
    480kg
    1560*1200*960mm
    BYF-25
    2.5T
    12.62kw
    8kw
    550kg
    1650*1200*1150mm
    BYF-30
    3T
    14.35kw
    10kw
    680kg
    1560*1200*1150mm
    BYF-50
    5T
    17.72kw
    22kw
    1250kg
    2200*1050*1550mm
    BYF-80
    8T
    25.55kw
    30kw
    1800kg
    3400*1550*1800mm
    BYF-100
    10T
    34.31kw
    42kw
    2200kg
    3550*1550*2050mm
    BYF-120
    12T
    38.8kw
    55kw
    3000kg
    3720*1650*2050mm
    BYF-150
    15T
    49.35kw
    69kw
    3600kg
    4000*1850*2400mm
    BYF-200
    20T
    60.4kw
    86kw
    4200kg
    4200*2000*2914mm
    BYF-250
    25T
    78.85kw
    110kw
    5500kg
    4500*2000*2450mm
    BYF-300
    30T
    102.45kw
    125kw
    6800kg
    5200*2200*3000mm
    BYF-350
    35T
    115.35kw
    140kw
    7600kg
    5200*2200*3200mm
    BYF-400
    40T
    147.35kw
    180kw
    8900kg
    5600*2400*3600mm
    BYF-500
    50T
    176.3kw
    220kw
    9800kg
    5800*2500*4500mm
    BYF-600
    60T
    214.9kw
    280kw
    10500kg
    6400*2500*4500mm
    Detailed Images
    1) Internally-scraping ice skate can help reduce energy consumption and prevent leakage of refrigerant.
    2) stainless steel materials, advanced processing equipment and heat treatment processing ensure the best heat transfer
    efficiency.
    3) The design of large water receiving plate can prevent water leaking at the bottom of evaporator.
    4) Direct liquid feeding and dry evaporation, simple and safe to control.
    5) Integrated modular design, convenient to install and maintain.
    6) Flake ice is easy to crush and mold, with almost zero damage to the cooled products.
    7)The internal structure of the evaporator is specially designed to improve the heat-exchange efficiency and to keep the loop
    unblocked with special processing technology.
    8)The internally scraping ice making mode has been adopted, which reduces the loss of energy and avoids the leakage of refrigerant.
    Related Products
    Certificate
    CE
    M.2019.206.C0141
    Packing&Shipping

    Standard export packing

    Wood cases in standard container or less than container load
    Each set is wrapped in plywood case and transport in standard container
    Our Services

    Pre-sale service

    * Inquiry and consulting support
    * Sample testing support
    * View our Factory

    After-sale service

    * Training how to install the machine, training how to use the machine
    * Engineers available to service machinery overseas
    Company Introduction
    Yixing city Ice Source Refrigeration Equipment Limited is a comprehensive modern manufacture of all kinds ice making plants, cold room, high-efficiency cold air blower, energy-saving evaporative condenser, aluminum alloy pipe row and various civil constructions, combined with cold room engineering.

    ICS is located in Yixing, Wuxi, Jiangsu, CHINA. With over 20 year's successful experience in Chinese market, we focus on the technical innovation to improve the machine quality and strengthen innovation ability. By insisting on the spirit "unity, seeking truth, pioneering and dedication", we commit ourselves to research and development of new technology, striving to create a comprehensive refrigeration enterprise in China.
