Food Inspection Combine Metal Detector And Check Weigher
Combination Weight Checkweigher Machine
Food Metal Detector and Check Weighing Machinae is suitable for detecting the weight of various products and
whether it contains metal. There are two push rods that can
transfer the bag with excessive weight or light weight and the
product containing metal to the next device.
It is widely used in the detection of meat, frozen meat, sea food,
mushrooms, drinks ,fruits , Sugar, Salt and vegetables.
Principle:
Dynamic online weighing and overweight & underweight rejection.
Function:
It is used for checking if the finished products are within the
preset standard
weight range, and automatically reject the substandard ones by
dynamic
weighing and control system. Applicable for the chicken cages
weighing and packaged chicken parts checkweighing.
Features:
1. Humanized structure design, easy to operate and clean.
2. Automatic zero tracking.
3. Flexible adjustment, applicable to products of multi
specification range.
4. Resolution up to 16 bit weight measurement with 0.05% high
accuracy.
5. 100 products parameters can be preset and called out.
6. High precision original Germany HBM digital load cell.
7. Rejection method: airjet, flapper, pusher and sliding for
choice.
8. Weighing data output: RS232/485, USB, wireless data
transmission, local
network station management platform, cloud platform
Specification:
| Detection width : | 30-80 cm, Customized |
| Detection height: | 8-50cm Customized |
| Detection sensitivity: | See below table |
| Alarm mode: | The buzzer alarm, the motor automatically stop |
| Transfer speed: | 25 meter / min or you can select adjust speed |
| Power: | 100-265VAC, 50-60Hz (According to customer request) |
| Size: | (150-170)cm(L)*(80-90)cm(W)*(85-120)cm(H) |
| Reject system | Option |
The reality detector sensitivity depends on the products and
operating environment . Please kindly see below:
| Detected Height(mm) | 80 | 100 | 150 | 200 | 250 | 300 | 350 |
| Belt Width(mm) | 250 | 250 | 400 | 400 | 400 | 400 | 400 |
| Belt length | 1500 |
Detector sensitivity(mm) | Fe 0.8 | Fe 1.0 | Fe 1.2 | Fe 1.5 | Fe 2.0 | Fe 2.5 | Fe 3.0 |
| SUS 1.0 | SUS 2.0 | SUS 2.5 | SUS 2.5 | SUS 3.0 | SUS 3.5 | SUS 4.0 |
| N-Fe 1.0 | N-Fe 1.5 | N-Fe 2.0 | N-Fe 2.0 | N-Fe 2.5 | N-Fe 3.0 | N-Fe 3.5 |
| Speed of belt | 25M/min (Fixed speed) ; If you need adjust 5-40 M/min , please inform us before order |
| Load ability | 20KG |
| Count | 100 |
| Warning method | Sound and light alarm ; The belt can be stopped, continue run or
belt return ( the option you can selected in PLC controller) |
| Reject Ways | when has auto-reject system ,belt continue and rejecting the goods |
| Application | Non-package ,plastic package ,paper bag or box (non-metallic)
product |
| Work Environment | Temperature -10℃-40℃ ,relative humility 30-90% |
