    Reciprocating Water Well Duplex 10mpa Drilling Rig Mud Pump

    Ask Lasest Price
    Brand Name : ShiTan
    Model Number : BW250
    Certification : ISO9001
    Price : Negotiation
    Payment Terms : T/T, Western Union
    Supply Ability : 20000Set/Year
    Delivery Time : Within 7-12 days
    • Product Details
    • Company Profile

    Reciprocating Water Well Duplex 10mpa Drilling Rig Mud Pump

    Reciprocating Water Well Duplex 10mpa Drilling Rig Mud Pump


    Drilling Rig Mud Pump Product Description

    BW-250 (grouting pump) mud pump is a horizontal three cylinder reciprocating single acting piston pump with two cylinder diameters and four speeds. The displacement and hole depth can be adjusted at will according to the purpose. The deepest can be used with 1500 meter drilling rig, and can also be used for cement slurry grouting. The pump has the advantages of less energy consumption, flexible operation, high quality and durability, good decomposition and easy removal.

    Drilling Rig Mud Pump Specifications


    brand
    Shitan
    Reciprocating unitPlunger pump
    Driving modeElectric
    performanceNo blocking
    Conveying mediumSewage pump, impurity pump
    Number of impellersother
    Pump shaft positionhorizontal
    Impeller structureother
    Impeller suction modeSingle suction
    NPSH
    20(m)
    Suction diameter
    50-90(mm)
    Discharge diameter
    32-60(mm)
    weight
    780(kg)
    Voltage
    380/660/1140(V)
    power
    7.5-45kw(kw)
    Specifications
    BW150/BW160/BW250/BW320/BW450
    purposeother
    texture of materialcast steel
    modelBW series

    Drilling Rig Mud Pump advantages:


    The main features are as follows:

    1. It can meet the needs of large and small diameter drilling rigs with four gear flow, large flow regulation range and reasonable parameter selection. It can be used with XY-4 core drill and XY-5 core drill. It can meet the needs of different caliber, different hole depth and different geological core drilling.

    2. The piston is a bowl shaped self sealing S-type polyurethane rubber piston with nylon back, which greatly improves the service life.

    3. There are five dust-proof sealing rings on the pull rod to prevent the mud at the hydraulic end from entering the power end and the lubricating oil filter at the power end. It has been proved by many production tests that the seal is reliable and the performance is good. So that the service life of the gear is prolonged.

    4. The inlet and outlet valves are made of steel balls. The valve cover is equipped with sound reducing rubber pad to reduce the impact noise.

    5. The pressure gauge adopts BY-1 seismic pressure gauge with long service life.

    6. Compact structure and beautiful appearance. 7. Good detachability, easy to repair and move.

    FAQ


    1. Are you factory ?We are a 20 years factory. We are specialized in kinds of drilling rigs and related parts.

    2. What is your terms of delivery?EXW, FOB, CFR, CIF,

    3. About Packing:Standard export packaging,export wooden cases or iron cases.

    4. Terms of Payment:30% TT deposit,the balance before shipment

    5. Shipping Type:By sea or by air

    6. Ports of Shipment:Tianjin,Qingdao,Shanghai or other required ports

    7. Quality Control:We have our own experienced QC, strict inspection and testing for every order before shipment
