    IP65 7" 16.7M Color HMI Touch Screen With Ethernet Port

    Ask Lasest Price
    Brand Name : adia
    Model Number : YD070Z11SL40GK
    Price : 60USD
    Supply Ability : 1KK/M
    Delivery Time : 20-25
    • Product Details
    • Company Profile

    IP65 7" 16.7M Color HMI Touch Screen With Ethernet Port

    Parameter summary Display: 7 "1024 * 600 24bit 16.7M color 7" TFT Color Touch Screen HMI with Ethernet Port

    1.1. Parameter summary

    1) Display: 7 "1024 * 600 24bit 16.7M color

    2)CPU:SuperV Z11s ARMCortex-A7 1.2GHz 512Mbit DDR2

    3) Storage: 128Mbit norflash

    4) Power supply: DC 5V, 600mA

    5) Storage temperature: - 30 ~ 80 ℃

    6) Working temperature: - 20 ~ 70 ℃

    7) Display brightness: 450cd / M

    8) Touch screen: gt911 capacitive touch p + G material

    SpecificationsItemsSK-070FS; SK-070HS
    DisplayDimension7" ( Length x Width = 16:9 )
    Resolution800 x 480
    Touch Panel4- wire high precision touch panel
    Display Color266,144
    Backlight UnitLED
    Contrast450:1
    Brightness450cd/sqm
    SD CardYes / Yes
    Memory128M/FLASH + 64M DDR
    CPU32-bit 600MHz A8
    Protection GradeIP 65 Front Panel
    Housing MaterialEngineering Plastics: ABS+PC
    Power SupplyPower SupplyDC24V(+/-15%)
    Power Consumption6w
    InterfaceSerial InterfaceCOM1: RS232/422/485 and COM2: RS232/422/485
    USB Download PortYes / Yes
    USBYes / Yes
    RJ 45Yes / Yes
    EnvironmentOperation Environment
    Temperature
    ~10 to 65C
    Operation Environment
    Humidity
    10 ~ 90% RH
    Anti-Vibration10-25Hz( XYZ direction 2G/30 minute)
    MechanicalDimension
    (width*height*depth mm)
    AS: 228 x 154 x 41mm
    BS: 203 x 145 x 40mm
    Cut-out
    (width*height mm)
    AS: 211 x 145mm
    BS: 192 x 138mm
    Weight1.5kg
