    50kN Hydraulic Cable Stringing Equipment For Transmission Line Construction

    Ask Lasest Price
    Brand Name : XINYA
    Model Number : SA-YQ50
    Certification : ISO
    Price : USD40000-50000/set
    Payment Terms : L/C, T/T,
    Supply Ability : 10sets/month
    Delivery Time : 30 workdays after payment
    • Product Details
    • Company Profile

    50kN Hydraulic Cable Stringing Equipment For Transmission Line Construction

    50kN hydraulic cable puller machine cable stringing equipment for transmission line construction


    Application:

    Hydraulic cable puller machine is a kind of efficient traction equipment when tension of transmission line is erected. It can be used for traction and deployment of single conductor, double-split conductor and four-split conductor in flat, mountainous and hilly terrain. It can also be used for OPGW or ADSS cable traction display in various terrains.


    Features:

    1. The traction force and speed can be adjusted steplessly and displayed intuitively.

    2. Color LCD display for engine parameters.

    3. Traction force can be preset with overload protection.

    4. Pressure-loss automatic braking function to ensure the safety of the operation when the engine suddenly stalls or other reasons cause the system to lose pressure.

    5. Hydraulic traction rope clamping device, easy to replace wire rope tray.

    6. The engine is equipped with a preheating device. The engine manual pump and diesel filter are easy to operate.

    7. With automatic winding device of steel wire rope, it is convenient to arrange rope automatically and to load and unload.


    Data Sheet

    ItemProduct modelSA-QY-50
    Performance parametersRated traction50kN
    Maximum traction60kN
    Rated traction speed2.5km/h
    Maximum traction speed5km/h
    Corresponding traction force25kN
    Structural parametersTraction drumBottom diameter450mm
    Number of rope grooves7
    Pitch distance42mm
    Groove depth10mm
    Maximum applicable diameter of wire rope18mm
    Dimensions3280×1900×2000mm
    Weight3000kg
    Main configurationsEngineCUMMINS
    Electrical system24V
    Hydraulic pumpREXROTH
    Hydraulic motorREXROTH
    ReducerREXROTH
    Tailstock winding motorDANFOSS
    Hydraulic instrumentWIKA
    Main hydraulic valvesATOS
