    4V21008 Truck Gearbox Parts

    Ask Lasest Price
    Brand Name : ZIQUN
    Model Number : 4V210-08
    Certification : ISO90001
    Price : Negotiable
    Payment Terms : Western Union, MoneyGram, T/T, D/P, D/A, L/C
    Supply Ability : 50Pcs/14Days
    Delivery Time : 15-30Work days
    • Product Details
    • Company Profile

    4V21008 Truck Gearbox Parts

    4V21008 Truck Gearbox Parts


    4V210-08 Series Single Coil Reversing Air Solenoid Valve Directional Pneumatic Valve


    4V210-08 DC12V DC24V AC220V AC110V 1/4" 5 Way 2 Position Electric Solenoid Valve


    Category: Pneumatic Valves
    Type: 5/2 Way Internally Piloted Acting Type Single Solenoid Valve
    Model: 4V210-08
    Port Size: 1/4" BSPT
    Effective area: 16mm2
    Operating temperature range:-5~55℃
    CV Value: 0.78
    Coil power: 3VA
    Working pressure range: 0.15~0.8MPa
    Proof pressure: 1.05MPa
    Voltage range: ±10%
    Power consumption: AC:1.3W DC:1.5W
    Insulation and protection: Class F.IP65
    Wiring method: Lead and box
    Frequency: 5/S
    Response time: 50ms
    Weight: 201g


    4V200 Series Solenoid Valve,Pneumatic Control Valve
    Model4V210-064V220-064V230C-064V230E-064V230P-064V210-084V220-084V230C-084V230E-084V230P-08
    4A210-064A220-064A230C-064A230E-064A230P-064A210-084A220-084A230C-084A230E-084A230P-08
    Position and Way NO.Two-position Five-wayThree-position Five-wayTwo-position Five-wayThree-position Five-way
    Effective Sectional Area14mm²(CV=0.78)12mm²(CV=0.67)16mm²(CV=0.89)12mm²(CV=0.67)
    Port SizeAir inlet=Air Outlet=Exhaust=G1/8"Air inlet=Air Outlet=G1/4' Exhaust=G1/8"
    Working MediumAir (40Micron Filtered)
    Acting TypeInner Guide Type
    Working Pressure0.15~0.8MPa
    Max.Pressure Resisance1.2MPa
    Working Temperature5~50°C
    Voltage Range±10%
    Power ConsumptionAC:5.5VA DC:4.8W
    Insulation&Protection ClassF Class.IP 65
    Wiring FormLead wire or Connector type
    Max.Frequency5 Cycle/Secretary
    ShortestActivate Time0.05 Second
    • Product Name :Pneumatic Solenoid Valve
    • Model : 4V210-08
    • Type : Two-position Five-Way
    • Power Consumption:12V 24V 110V 220V or Custom
    • Working Temperature Range: 5~50°C
    • It's applicable in many fields: Irrigation controls (garden, farm,etc.), liquid controls ( pipeline, artificial river etc. and air controls ( lab, factory, etc.)
    • We have solenoids available in AC/DC and various size NPT threads as welll

    Product features

    * Die-Casting valve body;

    * Big Flow; 　

    * Light-Weight;

    * Good storage function.

    4S 2 10 - 08 - □ - AC220V

    4S→Type Code

    4S: 5Port,2Position

    2→Series Code

    1: 100 Series 2:200 Series

    3: 300 Series 4:400 Series

    10→Coil

    10: Single control 20:Doule control

    30C: Doule control 3Position Center Close

    30E: Doule control 3Position Center Exhaust

    30P: Doule control 3Position Center Pressure


    4V330C-10 series double coil directional solenoid valves

    Feature

    　* Stable life cycle,guaranteed 10,000,0000 times; 　* Various voltage and working style are available; * Different surface treatment,thread types (G,NPT,PT,BSPP,BSPT)are available.
    Model
    4V130C-M5
    4V130C-06
    4V230C-06
    4V230C-08
    4V330C-08
    4V330C-10
    4V430C-15
    Working Medium
    Clean air(40μm Filteration)
    Acting Type
    Internal Guide
    Joint Size
    Import=M5 Export=M5 Exhaust=M5
    Import=1/8 Export=1/8 Exhaust=1/8
    Import=1/8 Export=1/8 Exhaust=1/8
    Import=1/4 Export=1/4 Exhaust=1/4
    Import=1/4 Export=1/4 Exhaust=1/8
    Import=3/8 Export=3/8 Exhaust=1/4
    Import=1/2 Export=1/2 Exhaust=1/2
    Sectional Area
    5mm2 (CV=0.28)
    9mm2 (CV=0.50)
    12mm2 (CV=0.67)
    12mm2 (CV=0.67)
    18mm2 (CV=1.0)
    18mm2 (CV=1.0)
    30mm2 (CV=1.67)
    Working Pressure
    0.15~0.9Mpa
    Max.
    Pressure
    1.2Mpa

    Working

    Temperature
    -5~60℃
    Voltage Range
    -15%~10%

    Heat Resistant Grade

    B
    Protective Class
    IP65(DIN40050)
    Coil Type
    Din type,Flying leads
    Max.Acting Frequency
    3Times/S

    08→Joint Size

    06: G1/8" 08:G1/4" 10:G3/8" 15:G1/2"

    □→Coil Type

    Blank:Din Type

    I:Fly leads

    AC220V→Standard Voltage

    DC12V DC24V

    AC24V 50/60HZ AC110V 50/60HZ

    AC220V 50/60HZ AC380V 50/60HZ

    Model
    4S110-06
    4S210-08
    4S310-10
    4S410-15
    Working Medium
    Clean Air(40µm filteration)
    Acting Type
    Internal Guide
    Joint Size
    Import=1/8
    Export=1/8
    Exhaust=1/8
    Import=1/4
    Export=1/4
    Exhaust=1/8
    Import=3/8
    Export=3/8
    Exhaust=1/4
    Import=1/2
    Export=1/2
    Exhaust=1/2
    Sectional Area
    18mm2
    18mm2
    50mm2
    50mm2
    Flow
    799NI//min
    799NI//min
    1554NI//min
    2220NI//min
    Working Pressure
    0.2~0.8Mpa
    Max. Pressure
    1.2Mpa
    Working Temperature
    -5~60℃
    Voltage Range
    -15%~10%
    Heat Resistant Grade
    B
    Protective Class
    IP65(DIN40050)
    Coil Type
    Din Type,Flying leads
    Max. Acting Frequency
    5Times/S
    4Times/S
    3Times/S
