300kgs 150kg Digital Balance Load Cell for Hopper Weighing

  • Product Details
  • Company Profile

300kgs 150kg Digital Balance Load Cell for Hopper Weighing

300kg Weight Sensor Gram 300kgs Load Cell 150kg Digital Balance Load Cell for Hopper Weighing

Internal calibration weighing scale
1.Label printing, 2.label format, 3.Counting,4. Checking,5. Percentage,6. Density

7.Internal Calibration,8.Barcode,9.Under weighing,10.Remote Display,11.Barcode


Technical Parameter
Rated Load0.5t,1t,2t,3t,5t,10t
Sensitivity2.0000±0.002mV/V
Total Error±0.02%F.S
Creep(30minutes)±0.02%F.S
Recommended Excitation Voltage5V~12V(AC or DC)
Maximum Excitation Voltage15V(AC or DC)
Zero Balance±1%F.S
Input Impedance380±10Ω
Output Impedance350±5Ω
Insulation Impedance≥5000MΩ
Safe Overload150%F.S
Ultimate Overload200%F.S
Operating Temperature Range(-30~+70)℃
Compensated Temperature Range(-20~+60)℃
Temperature Effect On Load±0.02%F.S/10℃
Temperature Effect On Zero±0.02%F.S/10℃
ConstructionAlloy Steel
Protection ClassIP67
CitationGB/T7551-2008/OIML R60
Mode of ConnectionInput+E:Red
Input-E:Black
Output+S:Green
Output-S:White
Quality 300kgs 150kg Digital Balance Load Cell for Hopper Weighing for sale
