Overview
The far infrared tunnel sterilization oven is mainly used for
drying and sterilizing antibiotic bottles, oral liquid bottles and
other glass bottles in such industries as medicine, health
products, etc.
Main Features
-The bottle is dried and sterilized by using the heat radiated by
white quartz heating tubes.
-The equipment includes three areas: preheating zone, heating and sterilizing zone, and cooling zone
with such mechanisms as conveying mechanism, exhausting mechanism
and electrical control mechanism.
-Preheating zone: It is equipped with fan with adjustable air
volume. Positive pressure is formed in the preheating zone. It is
also provided with 100-grade laminar flow equipment to prevent
particles in the air from entering the heating zone.
-Heating and sterilizing area: It consists of heating incubator,
and upper and lower rows of white quartz
heating tubes. It is provided with dehumidifying air outlets and
automatic humidity control device with uniform temperature.
-Cooling zone: It is equipped with cooling fan. The bottle after
drying and sterilizing enters the cooling zone and is air-cooled.
The air volume can be adjusted. Positive pressure is formed in the
cooling zone. It is also provided with 100-grade laminar flow
equipment to prevent particles in the air from entering the heating
zone.
-Conveying mechanism: It adopts stainless steel chain-driven type
mesh without any deviation. Stable running, variable frequency
speed control.
-Exhausting mechanism: It is provided with exhaust fan and exhaust
air duct. The exhaust air volume can be adjusted to ensure uniform
air pressure throughout the oven tunnel.
-Electrical PLC control system: All fans of the whole machine adopt
variable frequency speed control and touch screen operation
interface. Automatic temperature rise. It can realize fully
automatic control when connected with other equipment.
Main Technical Parameters
| Model | HX420/4500 | Conveyor belt effective width | 420mm |
| Sterilization temperature | 100-350℃ | Actual power consumption | 20kw |
| Electric heating power | 30kw | Total power | 35kw |
| Outline dimension(mm) | 200-700 bottles/minute (depending on the bottle type) |
About us
-Listed company founded in 2003(WINLONG GROUP CORPORATE)
-17 years’ manufacturing experience in the aseptic filling
production line.
-Exclusive manufacturing factory of 20,000 square meters
(Changzhou, Jiangsu)
-More than 100 famous enterprise business partners across China.
-Expanded global business network
-Proven design, efficient and reliabile products.
-Customized design to meet the customer’s demand.
Our Services and Warranty
1.We can customize the machine as customer required.
2.Available for OEM/ODM service.
3.Offer living broadcast or video support.
4.To Door installation and training service.
5.Offer filling line solution with customer requirement.
6.Customer’s design are welcomed.
7.Competitive price with on-time delivery.
8.Main spare parts one year warranty ( personal damaged except ).
We can customize with your packaging materials, production capacity
and demands.
We will provide you with associated design solutions and case
videos.
