    388H 4 Wheels Steering 2.5 Ton Backhoe Loader with 6 in 1 Bucket

    Ask Lasest Price
    Brand Name :
    Model Number : 388H
    Certification : CE/ISO9001
    Price : Negotiable
    Payment Terms : T/T, L/C
    Supply Ability : 1000 units/month
    Delivery Time : 15 days
    • Product Details
    • Company Profile

    388H 4 Wheels Steering 2.5 Ton Backhoe Loader with 6 in 1 Bucket

    388H 4 Wheels Steering 2.5 Ton Backhoe Loader with 6 in 1 Bucket
    1. Model: 388H
    2. Loader rated load: 2500kg
    3. Operation weight: 10500kg
    4. Loader bucket: 1.2m3
    5. Digger bucket: 0.3m3
    6. Engine: YUCHAI YC4A105Z-T20
    7. Rated power: 75kW/2200r/min

    388H backhoe loaders is upgraded on the basis of the mature equipment and technical performances of present
    products,including the upgrade of engine emission, lightweight upgrade of structural parts, and of working device
    parameters, to further improve the comfort, safety, maintainability, reliability, supportability, and economy of the
    product.

    Advantages and Highlights:
    1. Enlarged operator cabin, with secure glass, is capacious and bright some.
    2. Working table, water temperature, oil temperature, current, work timing are all in sight.
    3. Famous brand hydraulic components are adopted, two gear oil pump work together, the power is driving and loading and dumping can change freely.
    4. Adjustable seat, convenient and comfortable to use.
    5. Rear and front body, with smell rotary radius, hydraulic steering, comfy and convenient to operate.
    6. Hydraulic traction, the moving arm can leveled skid and expend digging range.
    7. Completely have the all functions of mini type digging machines.
    8. Ascendant performance of complete appliance, with extraordinary operation efficiency.
    9.With which many kinds of optional components can be matched to meet requirements of different users.
    Product Parameter of 388H All Wheels Steering Hydraulic 2.5ton Backhoe Loader

    Overall dimensionOperating Weight10500KG
    Overall dimension(L×W×H)6450×2530×3120mm
    Wheel base2335mm
    Wheel tread2050mm
    Ground Clearance450mm
    PerformanceLoader bucket capacity1.2m³
    Loader breakout force47KN
    Loader lifting capacity2500KG
    Loader dumping height3050mm
    Loader dumping reach870mm
    Loader digging depth52mm
    Backhoe bucket capacity0.3m³
    Backhoe bucket digging force50KN
    Backhoe swing angle180°
    Backhoe dumping height4050mm
    Backhoe max digging depth3820mm
    Max. traction force86KN
    EngineModelYuchai YC4A105Z-T20
    TypeTurbocharging four-stroke
    Cylinder-inner diameter*stroke4-108×132
    Rated power75KW/100HP
    Rated speed2200r/min
    Min. Fuel consumption230g/kw.h
    Max.torque400N.m
    Displacement4.8L
    Steering systemTypeHydraulic Steering
    Diverter modelBZZ5-250
    Pump delivery63ml/r
    Steering angle±35°
    Min. turning radius6950mm
    Driving axleModelWZL100DF
    ManufacturerChina axle
    Max. load of front axle13 ton
    Max. load of rear axle13 ton
    TransmissionGearboxMechanically Operated Hydraulic Synchrinized Shift
    ModelZL30
    Gears4 forward and 4 reverse gears
    Hydraulic torque converterYJ320
    Inlet pressure0.4-0.65Mpa
    Outlet pressure1.6-1.9Mpa
    Cooling modeoil-cooling presssure circulation
    Pump delivery40ml/r
    WheelFront wheel size16.9-28
    Rear wheel size16.9-28
    Front tire pressure0.35Mpa
    Rear tire pressure0.35Mpa
    Travel speed38Km/h
    Brake systemService brakeGas pushed oil, built-in-selfregulation, self-balance
    Parking brakeManual brake
    System pressureLoading hydraulic system20Mpa
    Digging hydraulic system20Mpa
    Steering hydraulic system14Mpa

    388H All Wheels Steering Hydraulic 2.5ton Backhoe Loader for Sale
