ASTM A213 TP304, TP304L , TP316L , TP321 , TP310S, TP347H , TP317L ,16 BWG 20FT Heat Exchanger Tube

Name: ASTM A213 TP304 TP304L TP316L TP321 TP310S TP347H TP317L 16 BWG 20FT Heat Exchanger Tube
Brand: YUHONG
Price: 1 USD

Ask Lasest Price
Brand Name :	YUHONG
Model Number :	ASTM A213 / ASME SA213 TP310S / TP310H
Certification :	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Price :	negotiable
Payment Terms :	T/T, L/C
Supply Ability :	1500 tons per month
Delivery Time :	10days->

Add to Cart

Product Details
Company Profile

ASTM A213 TP304, TP304L , TP316L , TP321 , TP310S, TP347H , TP317L ,16 BWG 20FT Heat Exchanger Tube

Stainless Steel Seamless Tube, ASTM A213 / ASME SA213 TP310S / TP310H , 3/4" 16 BWG 20FT, 100% ET & HT

YUHONG Group deal with Austenitic Stainless Steel, Nickel Alloy Steel(Hastelloy , Monel, Inconel, Incoloy ) seamless and welded pipe and tube already more than 25 years, every year sell more than 80000 tons of steel pipe and tube. Our client already cover more than 45 countries, Like Italy, UK, Gernmany, USA, Canada, Chile, Colombia, Saudi Arabia, Korea, Singapore, Austrial, Poland, France , ....And our group branch company and factory have been already approved by :ABS, DNV, GL, BV, PED 97/23/EC, AD2000-WO, GOST9941-81, CCS, TS, CNNC, ISO9001-2008, ISO 14001-2004.

ube Sizes for Heat Exchangers & Condensers & Boiler

Outside Diameter			BWG
		25	22	20	18	16	14	12	10
			Wall Thickness mm
		0.508	0.71	0.89	1.24	1.65	2.11	2.77	3.40
mm	inch		Weight kg/m
6.35	1/4	0.081	0.109	0.133	0.174	0.212
9.53	3/8	0.126	0.157	0.193	0.257	0.356	0.429
12.7	1/2		0.214	0.263	0.356	0.457	0.612	0.754
15.88	5/8		0.271	0.334	0.455	0.588	0.796	0.995
19.05	3/4		0.327	0.405	0.553	0.729	0.895	1.236
25.4	1		0.44	0.546	0.75	0.981	1.234	1.574	2.05
31.75	1 1/4		0.554	0.688	0.947	1.244	1.574	2.014	2.641
38.1	1 1/2		0.667	0.832	1.144	1.514	1.904	2.454	3.233
44.5	1 3/4				1.342	1.774	2.244	2.894	3.5
50.8	2				1.549	2.034	2.574	3.334	4.03
63.5	2 1/2				1.949	2.554	3.244	4.214	5.13
76.2	3				2.345	3.084	3.914	5.094	6.19
88.9	3 1/2				2.729	3.609	4.584	5.974	7.27
101.6	4					4.134	5.254	6.854	8.35
114.3	4 1/2					4.654	5.924	7.734	9.43
Form of Tube: Straight & U-bend & Finned & Coiled
Stainless Steel Tube: A/SA213, A/SA249, A/SA268, A/SA269, A/SA789, EN10216-5, A/SA688, B/SB163, JIS-G3463, GOST9941-81.
Carbon &Alloy Steel Tube: A/SA178, A/SA179, A/SA192,A/SA209, A/SA210, A/SA213

Specification:

ASME SA213/A213: Standard Specification for Seamless Ferritic and Austenitic Alloy-

Steel Boiler, Superheater and Stainless Steel Heat Exchanger Tubes.

ASTM A249 / A249M:Standard Specification for Welded Austenitic Steel Boiler, Superheater

Heat-Exchanger, and Condenser Tubes.

Other Standard:DIN 17456 , DIN 17458, EN10216-5, GOST 9940-81, GOST 9941-81, JIS-G3463,...

Product Item	Stainless Steel Heat Exchanger Tube
Grade	TP 304/304L, TP316/316L,TP 321/321H,TP317L, TP310S, TP310H, TP309S, TP314, TP329, TP347H etc
O.D.	6.35-101.6mm(1/4''-4'')
W.T.	0.71-14mm(0.028''-0.55'')
Size	OD ( 6.35-101.6mm ) * WT ( 0.71-14mm ) * MAX. 32M
Standard	ASTM A269, ASTM A312, ASTM A213 etc
Quality	MTC will be supplied with shipment, Third Party Inspection is acceptable
Application	Petroleum, chemical enterprise, super heater of boiler and heat exchanger High temperature-resistant transmission fluid pipe in power station Ship with pressure pipe Exhaust purification device Construction and ornament etc
Advantage	Advanced technology of cold draw machine; Advanced annealing machine; better mechanical property; more precise dimension; perfect inspection method and inspection equipment etc
Process Method	Cold Drawn/ Cold Rolled etc
Surface Finish	Annealed, Pickled etc
Package	Woven bags/Bundles In plywood cases Iron cases
Delivery Time	10-60 Days after receiving the deposit (Normally according to the order quantity)
Main Market	Europe, Middle East, Southeast Asia, South America. etc
Certificate	ABS, DNV-GL, BV, KR, LR, CCS, PED, TUV ,ISO9001, ISO 14001, ISO 18001

Type of Tubes:

U-bend & Straight.

Eddy Current Testing
O.P Testing
Radiography Testing

Corrosion Testing
Micro Testing
Macro Testing

IGC Testing
Ultrasonic testing
Liquid Penetrate testing
