BioSense Fingerprint 9590 Biometric Access Control System

Web-Based BioSense Fingerprint Access Control Standalone Terminal

Introduction:

Fingerprint Access Control Standalone Terminal

Biometric access controller for doors and time attendance clock machine with fingerprint security through web-based. Biosense features standard TCP/IP and RS485 interfaces for main communication between devices and the server. Biosense features an IP54 certified weatherproof exterior. IP54 protection allows system designers to place the terminal in both indoor and outdoor environments.

Fingerprint Recognition Security Access Control and Time & Attendance terminal.

Features:

Standalone access controller
Sub-controller, dummy reader modes.
Fingerprint / card / fingerprint + card verification mode.
Optical fingerprint sensor module.
Proprietary software (SoMac) support.
Built-in HTTP server.

Specifications:

Software Application: SoMac
Verification Mode: Fingerprint / Card (Not support Keypad)
Template Capacity: 9,590
Sensor Type: Optical
Resolution: 500dpi
Sensing Area: 16 x 19mm
Template Size: 256 ~ 384 Bytes
Image Size: 272 x 320 (pixel)
1:1 Verification time: < 600msec
1:1,000 Identification time: < 760msec
Card Capacity: 20,000
Communications: TCP/IP, Wiegand/RS485
DIO Support: DI: 3 / DO: 1
Inbuilt Relays (Max. power loading): Door Lock (40VAC / 40VDC, 2A)
System Log: 1,536 entries
Entry Log: 51,968 entries
Time Zone / Time Set / Group: 255 / 120 / 255 Sets
Holiday: Yes
Remote Control / Event Handle: Yes / Yes
Fast Registry: Yes
Function Key (Auto): 400 (set BF-670W as Controller)
Anti-Pass Back: Yes
Power Consumption: 500mA ± 5%
Power Requirement: 9 ~ 24VDC / 1A
Operation Temperature: 0°C ~ 65°C
Operation Humidity: 5% ~ 80% RH
Dimension / Weight: 160 x 56.9 x 40.1mm / 150g
