    21.5 Inch Embedded Capacitive Openframe Touch Monitor For self-service terminals

    21.5 Inch Embedded Capacitive Openframe Touch Monitor

    For Self-Service Terminals


    INTRODUCTION

    The Touch Screen allows users to operate the host as long as they lightly touch the icons or text on the computer display with their fingers, which eliminates keyboard and mouse operations and makes human-computer interaction more straightforward. Mainly used in public hall information query, leadership office, electronic games, song ordering, multimedia teaching, air ticket/train ticket pre-sale, etc. The products are mainly divided into three categories: capacitive touch screen, resistive touch screen and surface acoustic wave touch screen.

    • Standard sizes List for PCAP touch overlay:

    10.1'',10.4",12.1",13.3'',15",15.6",17",17.3",18.5'',19",21.5",22",23",23.6",24",27",32",42'',43'',49'',50'',55'',65''


    Main Features
    1. Integrated solution for touch function and liquid crystal display
    2. USB touch interface for flexible customer selection
    3. Long product life cycle, upgrade or replacement of LCD screen will not cause external dimensional changes
    4. High brightness, high contrast, fast response time, multi-color support, wide viewing angle
    5.A variety of mounting options, including horizontal mounting bracket mounting, vertical mounting bracket mounting, VESA standard mounting, and customer self-designed mounting
    6.Flat-panel capacitive touch for a stable and sensitive touch experience and high-definition visual enjoyment
    7.Can adapt to various customization requirements of customers

    Model
    KER
    Peoduct serial
    Wateproof and dustproof
    Touch Area
    476.064×267.768 mm
    LCD Type
    21.5” TFT-LCD Brand:CMO/AU/BOE/CHIMEI ETC
    Video Input
    VGA ,DVI,HD)MI,USB,AUX,DC,AUDIO etc.(optional)
    Recommend Resolution
    1920*1080
    OSD controls
    Allow on-screen adjustments of Brightness, Contrast Ratio,
    Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset
    Power Supply
    Type: External power adapter Input voltage: 100-240 VAC, 50-60 Hz
    Mount Interface
    1)VESA 75mm and 100mm 2)Mount bracket, horizontal or vertical
    LCD Specification
    Active Area(mm)
    476.064×267.768 mm
    Resolution
    1920*1080
    Viewing angle (v/h)
    89°/89°
    Contrast
    1000:1
    Luminance(cd/m2)
    350-1000cd/m2 - optional
    Support Color
    16.7M , 73% (CIE1931)
    Remarks: LCD related parameter indicators are adjusted according to the selected LCD brand and model
    Touchscreen Specification:
    Type
    WiViTouch PCAP Touch screen(Receive custom PCAP)
    Resolution
    4096*4096
    Light Transmission
    92%
    Touch Life Cycle
    50 millions
    Touch Response time
    8ms
    Touch System Interface
    USB interface
    Power consumption
    +5V
    Glass
    3mm vanda-proof glass, optional AG( anti-glare) or AR glass
    External AC Power Adapter:
    Power Input
    12V/DC/4A
    Power Output
    100-240 VAC, 50-60 Hz
    MTBF
    50000 hr at 25°C
    Before you start to set up the LCD Monitor, please check the following items ready in the
    accessory box:
    A) 1pcs 12V power adapter;
    B) 1pcs power cable;
    C) 1pcs 1.8m long VGA cable (or HDMI cable, DVI cable, according to interface configuration);
    D) 1pcs 1.8m USB cable
