19mm large Current 10A Waterproof Push Button Switch self-reset
self -lock Flat rOund head 1NO
Product Features
- 19MM 10A current 250V AC , 2 Terminal Pin,1NO or 1NC are
available.
- IP Degree: Most of our products are IP67, some of them IP65, 6
means Totally protected against dust,7 means Protected against the
effects of temporary immersion between 15cm and 1m. Duration of
test 30 minutes, 5 means Protected against low pressure jets if
water from all directions - limited ingress permitted
-
| Product Description |
| Product name | 10A Large current Metal push button switch |
| Produstion Type | GQ19AF-10/S | GQ19AF-10/N |
| Body material | Stainless steel | Chrome plated brasss |
| Button material | Stainless steel | Stainless steel |
| Base material | PBT | PBT |
| Mounting hole size | 19mm |
| Max. Current | 10A |
| Max. Voltage | 250V AC |
| Contact structure | 1NO OR 1NC |
| Head shape | Flat Round Head |
| Emitting Type | NO LAMP |
| Lamp color | NO LAMP |
| Lamp voltage | NO LAMP |
| Product Parameter |
| Mechanical life | More than 1,000,000 times |
| Electrical life | ore than 200,000 times |
| Operating temperature | -25℃- +55℃ |
| Operating humidity | 45-82%RH |
| Operating distance | About 2mm |
| Operating pressure | About 3N |
| Protection level | IP67 |
| Insulation resistance | More than 1000MΩ |
| Contact resistance | ≤ 50mΩ |
Product dimension drawing and connection description
Product Application Scope
Product packaging
- Package : 40pcs/box, or 100pcs/box. 1 piece push button switches
with 1 robber ring.
- We are all packed in foam boxes.We promise that if there are any
problems with the products you receive, we will send them to you
again.
Product Transportation
We have cooperated with DHL, UPS, fedex and other logistics
companies.It can greatly save the transportation cost of products.
Our services
- We have a strong technical and customer service team to provide
strong after-sales support for customers.
- We can provide 3-5 free samples to customers for testing.
- If the product is damaged in transit, we can reissue it to the
customer free of charge.
- Every one of our products is strictly tested before we send it to
our customers.
- If there is any problem with the product you received, please
contact us for a replacement.
F&Q
Q:What is the supply capacity of your factory?
- A: Our production capacity can meet multiple orders at the same
time, will be delivered in the shortest time.
Q:How can we contact you to place an order?
- A:You can contact us by email or WHATSAPP, and we will reply to
you as soon as we see the information.
Q:How long is your product warranty?
- A:We ensure you a 3years quality guarantee.
