Direct Driven Spindle Multi Turrets CNC Turning Machine

Direct Driven Spindle Multi Turrets CNC Turning Machine

• Expanded machine functionality promises reduced cycle times.
• Suitable for a broad range of production processes.
• This machine's development was driven by the demands of entrepreneurial manufacturers.
• The CNCHardware GT260V combines the highest levels of reliability, accuracy and efficiency.
• As a result of large production volume and well managed supply chain, CNCHardware has produced a machine that operates at the highest levels of performance
• providing you with a powerful weapon for improving your competitive advantage.

CNC Turning Machine Standard Features

• Hydraulic 3-Jaw Chuck
• 8-Station Turret
• Full Guard
• Work Light
• Tri-Color Alarm Light
• Automatic Lubrication System
• Automatic Coolant System

CNC Turning Machine Optional Features

• 12-Station Turret
• Different Chucks and Collets
• Different CNC Control Systems
• Different Spindle Speed and Bore Dia
• Chip Conveyor
• Tool Setter
• Bar Feeder
• Gang Type Tool Holders
• Parts Catcher
• Tailstock
• Driven tool Turret

• CNCHardware provides a variety of lathe spindles to match the requirements of a wide range of industries. CNCHardware spindles have a wide range of cutting parameters with different spindle characteristics to match your unique turning requirement in a way that assures you maximum efficiency and profitability.
• CNCHardware’s 100% owned spindle manufacturing subsidiary is constantly researching and developing new spindles to match a broader range of customer turning requirements.
• The GT260V has a number of spindle options in order to optimize the efficiency of this dual spindle powerhouse - for your application.
• We are here to help you maximize your processes and help you make more, and better-quality parts.

Cartridge Type Spindle
The CNCHardware cartridge spindles are sealed within a stainless steel housing as a complete unit. Easily replaceable and securely matched with a machine headstock that provides the foundation for better spindle dynamic balancing accuracy. Works well in high speed applications.

Direct Mounted Spindle
The CNCHardware direct mounted option matches the headstock manufacturing and assembly for optimum accuracy.
Each manufactured headstock and spindle unit is assembled in a clean room under temperature controlled conditions.
The larger sized spindles are supported by a double row of tapered cylindrical roller bearings, plus angular ball bearings and a double row cylindrical roller bearing in the rear for increasing rigidity.
Small size spindle design adopts high precision angular ball bearing reduces noise and increases accuracy.

Direct Driven Spindle
This electric spindle (Built-In Motor) offers high acceleration and deceleration, which shortens cycle times and increases efficiency.
In addition, a machine with this spindle will operate with less vibration and lower noise.
It is excellent for applications where finish and extreme accuracy are important.



CNC Turning Machine Servo Turret
High Speed
The turret uses servo motors to shift the tool position which reduce tool change time essentially.
Heavy Duty
The turret uses hydraulic system to clutch.
Powerful tool clamping minimizes tool tip deviation due to load, which displays excellent performance during heavy duty cutting.
High Accuracy
The turret uses high-precision tooth couplings for accurate positioning.
As double channel system with double turrets, all those advanced technology enlarged 2 times on GT260V.
Machining cycle time is reduced, which improves productivity tremendously.
