Product Description
The intelligent power-on test system conforms to GB 1985-2004, GB
311.1-2012, GB 1984-2014, DL/ t596-2005 and other relevant national
standards.
The device provides a variety of AC and DC voltage and current
output channels, which can be used for electrically test of routine
test and type test of high and low voltage switching equipment.
The main control part of the device is completed by
high-performance CPU, equipped with wireless keyboard and mouse,
equipped with intelligent touch screen, support intelligent
testing, virtual dashboard display and control.
The logic control part of the device is completed by a special PLC
programmable logic controller, which realizes automatic switching
of control circuit and real-time feedback of line state.
Features
The intelligent power-on test system integrates data collection,
analysis and processing, measurement and control, data display,
storage, printing and protection, and the whole test process is
completed automatically, with outstanding advantages of high
efficiency and high precision.
The intelligent power-on test system adopts full computer operation
and displays parameters such as three-phase voltage and current at
the same time. All test data are displayed in real time (locked) on
the screen, which avoids errors caused by parallax, conversion,
calculation and other factors in the test process. Make the test
more accurate. In particular, it completely solves the difficulty
of operators reading and reading multiple meters and recording
multiple sets of data at the same time, so as to ensure the
accuracy and reliability of test data
The method of automatic storage is adopted for data processing. All
test data are filled into the corresponding database in real time,
so as to avoid manual transcribe and record process and ensure the
truth and reliability of the data.
Test Items
▼AC current output, 0-10A adjustable
▼AC voltage output, 0-690V adjustable
▼AC voltage output, 380V
▼AC voltage output, 220V
▼DC voltage current, 0-10A adjustable
▼AC voltage output, 0-220V adjustable
Technical Parameters
| Items | Range |
| Rated capacity | 16.5kVA |
| Rated voltage | AC380V+10% |
| Frequency | 50HZ+2% |
| Rated current | 25A |
| Phase | 3 phase |
Adjustable range of 3 phase AC current | AC 0-10A |
| Adjustable range of 3 phase AC voltage | AC 0-690V |
| Three-phase AC voltage | AC 220V/380V |
Adjustable range of single-phase DC voltage | DC 0-220V |
| Work condition | Operating temperature: 0-40℃ Relative humidity: 30%-90% |
