1-2ton per Batch Grain Bin Dryer,Small Grain Dryer Machine,Mini
Grain Dryer
Description:
1. The working principle of the ventilating dryer comes from the
traditional manual drying grain. The traditional way of grain
drying has many disadvantages, such as time-consuming, large area,
uneven drying and low efficiency.
2. YTSJ480 series dryers are specially used for drying grain and
crops with small output, transforming the traditional manual mode
into semi-automatic mode. It greatly reduces the cost of human
resources, saves the land area, improves the output and efficiency,
and maximizes the economic benefits of farmers.
3. Dried products: garlic, rice, herb seeds, bamboo chopsticks,
groundnuts, black beans, wheat, corn, feed, cocoa beans, coffee
beans.
| Name | YTSJ480G | YTSJ480C |
| Heating Way | Direct | Indirect |
Max. Combustion liter/hr | 3.3 | 4.4 | 6.6 | 3.3 |
| Temp. Range Ambient Temp.°C | +10-36 | +22-48 | +40-65 | +10-20 |
| Application | Garlic, Seeds, Paddy, Chopsticks, Peanut, Wooden Products | Wheat, Corn, Jackfruit, Animal Feed | Wheat, Corn, Salted Peanut, Sunflower Seeds, Dry Longan, Duck
Feather, Animal Feed, Goose Feather, Cocoa Bean, Coffee Bean | Suitable for food products that require cleanliness. Ex: medicine,
sliced onion, sliced garlic,etc. |
| Fuel | Kerosene or Premium Diesel | Kerosene | Kerosene or Premium Diesel |
| Safety Devices | Thermo-over Relay,Air Pressure Switch, Pressure Switch, Flame
Sensor, Control Fuse. | Thermo-over Relay,Air Pressure Switch,Flame Sensor, Control Fuse |
| Electricity | 1P,220V, 50Hz 3P,380V, 50Hz | 1P,220V, 50Hz 3P,380V, 50Hz |
| Power Consumption | | 0.75kw | | 0.75kw |
Dimension LxWxH | 3878x2465x870mm | 3235x2465x870mm |
| Net Weight Approx. | Single Layer 455kg; Double Layers 540kg
| Single Layer 480kg; Double Layers 565kg |
| Drying Bin | Single Layer 2.5m3 | Double Layers 5.84m2 | | Single Layer 2.5m3 Double Layers 5.84m2 |
| Kerosene or premium diesel must meet your national standard. Must
use premium diesel that can completely atomize at your local
ambient temperature. |
