    High-Performance CNC Automatic Steel Rule Die Bending Machine

    Ask Lasest Price
    Brand Name : Perfect Laser
    Model Number : PEC-100
    Certification : CE / ISO / FDA / SGS / TUV
    Price : Negotiable
    Payment Terms : T/T, L/C
    Supply Ability : 5000 Units Per Year
    Delivery Time : 10-15 Working Days
    • Product Details
    • Company Profile

    High-Performance CNC Automatic Steel Rule Die Bending Machine

    High-performance CNC Automatic Steel Rule Die Bending Machine

    (Model: PEC-100)


    Product Description Of Auto Blade Bending Machine


    PEC-100 blade automatic bending machine, also known as automatic steel rule die bending machine, indentation cutting rule bending machine, laser die bending machine, steel rule bending machine, automatic die cutting bending machine, precision steel rule bending Bending machines, etc., suitable for cutting templates in the packaging and printing industries. Widely used in the production of carton corrugated box molds, shoe molds, blister molds, Clicker molds, label electronic molds, process molds, acrylic molds, leather molds, foam molds, etc. The PEC-100 automatic steel rule die bending machine can be used with a template cutting machine to bend the blade embedded in the template. The automatic steel rule die bending machine is mainly composed of a feeding shaft, a bending shaft and a cutting shaft.


    Product Features Of Auto Blade Bending Machine


    1. Reduce labor costs and improve work efficiency. Various operations such as bending, bridging, and beak can be completed on one blade automatic bending machine.

    2. Fully automatic bending, direct calibration after bending, no additional cutting or grinding required, saving time and labor.

    3. On the automatic blade cutter, the cutting method does not cause the blade to curl, which avoids the disadvantage of edge curl caused by traditional single-blade cutting.

    4. The automatic blade cutter uses Japanese high-performance servo motors and imported mold steel bending dies, which are fast and accurate, and are suitable for the production of complex graphics such as compact box molds, cartoon molds, and doll molds.


    Structure And Appliacation Of Auto Blade Bending Machine



    Detailed Images Of Auto Blade Bending Machine


    Specifications Of Auto Blade Bending Machine


    Device NameBlade Bending Machine
    ModelPEC-100
    Feeding Accuracy±0.3mm
    Maximum Bending Angle110°
    Motor

    Feeding, bending:

    Japan imported servo motor, 400W x 2

    Bridge: 750W x 1

    Rail ScrewTaiwan TPI
    Blade Size

    Thickness: 0.71mm / 1.07mm (0.45mm / 0.53mm optional);

    Height: 23.8mm (conventional), can up to 30mm;

    Bridge Height15mm / 18mm
    Air Compressor Pressure0.5-0.8mpa
    Tracheal Diameter10mm
    Optional DeviceFeeding table cover
    Support File FormatDXF
    Total Power1.5 KW
    VoltageAC/ 220V / single phase
    Dimension2800 x 730 x 1310mm

    Sample Show Of Auto Blade Bending Machine




    Packaging & Delivery


    1. Prompt deliver at the very day.
    2. Sophisticated and professional logistic agent.
    3. Well-trained and disciplined packing team.
    4. After-sale service:. Any questions or problems after receiving the product, please feel free to contact us. Problems would be solved for you immediately.

    Competitive Advantages


    1. We offer high quality products at competitive price in quick delivery.
    2. 100% custom pass guaranteed.
    3. Good after-sale service.
    4. Flexible and Untraceable payment terms.
    5. Our products have been exported to Germany, Norway, Poland, Finland, Spain, UK, France, Russia, USA, Brazil, Mexico, Australia, Japan, Korea, Thailand, Indonesia, Uruguay and many other countries.
