Smart PID Controller For Pressure Control Excellent Anti Interference Performance

PID intelligent pressure controller PD9001 excellent anti-interference performance

PID intelligent pressure controller PD9001 excellent anti-interference performance

PD9001 is PID intelligent pressure controller integrate a number of international advanced electronic & Single-chip computer technology ,meanwhile with high cost performance and adaptability of the fluctuate conditions of power grid can completely replace the same imported high-grade pressure controllers or controllers overseas. the beautiful shape , complete functions & excellent anti-interference performance to ensure the stability and reliability of the system.

The instrument technical indicators are as follows:

Digital Display : Double layer double color four digital display ( green and red )
Electronic bar display: 20 segments electronical bar indicate the output power
The range of display : 0000～9999 (radix point alterable)
Accuracy: 0.2%FS±1
Display of indicator light : AL-1,AL-2,CAE, MAN
Pressure range : programmable setting
Sampling frequency : 50times/s
Alarm output : two circuits with programmable alarm Settings
Input : 2mV/V,3.3mV/V,0～10mA,0～20mA,4～20mA,0～5V,1～5V,0～10V ( order stated )
PID output : 0～5V,0～10V,4～20mA ( order stated )
Work environment : 0～55℃ & ≤80%RH
Working power supply : 85～265VAC,50～60Hz；
Controller size : 96×96mm , Hole size : 92×92mm

Shanghai Zhaohui Pressure Apparatus Co.,Ltd. (ZHYQ) is the leading professional manufacturer in the industrial of pressure, flow, temperature, liquid level and Internet of Things (IoT).

ZHYQ found in 1999, based on the physical quantity of pressure, flow, temperature and level, developed a series of large scale and professional measurement products.

ZHYQ is ISO9001 (2015) Quality management certificated company, we acquired the certificates of CMC, Ex, MA, CE, RoHS and etc, till now we have applied for 7 Invention patents and more than 50 utility model patent technologies.

In recent years, ZHYQ actively expands the capacity and enhances to develop new products to meet the requirement of the market, found R&D center covers 1500㎡ and production base covers 10000㎡, annual yield more than 1 million pieces , the produces are widely used in the field of industrial process control, energy & electricity, hydrology, construction machinery, medical experiment, military equipment and etc, our market spread all over the world with more than 50 countries and areas.
