Oil Refinery Industrial Oil Press Machine Steam Circulation Mixing Decolorizer

TST 80-300 Steam circulation mixing decolorizer for oil refinery

1. Equipment structure, working principle and performance characteristics
At present, most domestic decoloring equipment is mainly mechanical mixing (straight or oblique mixing). This kind of equipment generally has the following problems: there is a mechanical leaking point at the joint of the mixing shaft and the equipment body, which makes it impossible to guarantee the proper vacuum in the equipment. Mechanical mixing has a dead angle, which affects the heating and adsorption effect. In addition, mechanical mixing increases power consumption. The continuous steam circulation decoloring equipment developed by Leader is suitable for continuous adsorption and decolorization of vegetable oils, and can be used to produce high-quality edible oils (such as advanced cooking oil and salad oil
a. Structure
The equipment is mainly composed of shell, partition board, overflow pipe, direct steam heating pipe, and liquid level control system. The upper body of the shell is equipped with manhole and sight glass.
b. Working process
The oil to be decolorized is mixed with quantitative clay in a premixing tank, and after preheating, it is pumped into the equipment body from the top of the decoloring equipment and falls on the first layer of the equipment body. Direct steam is injected for heating and blowing, when the liquid level reaches a certain height, the mixed slurry flows into the second layer through the overflow pipe, repeats the first layer operation, and then mixes and heats in the third layer, so that the white clay can fully absorb the pigment in the oil.z Finally, the mixed slurry of oil and white clay is extracted from the decolorizing equipment and entered into a vertical blade filter for waste white clay filtration.
c. Characteristic
c1.The superheated steam is used to blow the material to make the material turn evenly, avoiding dead angles and short circuits. Steam mixing is adopted to avoid vacuum leaking.
c2.The equipment is equipped with a liquid level automatic control device, which ensures the continuous and safe operation and minimizes human factors during the working process.
c3.The high-efficiency leaf filter is used to filter the waste white clay to realize continuous filtration. Low labor intensity, good environmental conditions, less residual oil in the waste white clay.
c4.Steam mixing saves motors, reduces manufacturing costs and equipment prices.
2. Main specifications and technical paramete
