Product Description
Product introduction:
1 The motor coil is dipped in vacuum environment, Class F insulation,
longer lifespan.
2 Convenient oil replenish structure, unique oil feeding hose.
Special designed for high temperature working environment.
3 Commonality, good applicability.
4 Special enhanced spindle&bearings, more stronger, Better
overload capacity.
5 Voltage: 380V/50HZ (Various voltage&frequency are available,
415V/380V/240/230V/220V/120V/110V, 50HZ/60HZ)
UAGW series high temperature resistance motor mainly applied to the
dying&printing processing industry, such as stretch setting
machine, decorating machine,printing machine.
UAGW Series motor Technical Parameters:
Model | Rated Power (Kw) | Rated Voltage (V) | Rated Frequency (HZ) | Rated Current (A) | Rated Torch (N.m) | Rated Speed (rpm) | Efficiency (η) | Power Factor | TS / TN | TMAX / TN | IS / IN | Noise | Weight |
112-4P | 4 | 380 | 50 | 8.54 | 26.3 | 1450 | 85.4% | 0.83 | 2.3 | 2.3 | 7.5 | 65 | 45 |
132-4P | 5.5 | 380 | 50 | 11.4 | 36.2 | 1450 | 86.1% | 0.86 | 2.0 | 2.3 | 7.5 | 71 | 60 |
132-4P | 7.5 | 380 | 50 | 14.9 | 49.4 | 1450 | 87.3% | 0.88 | 2.0 | 2.3 | 7.3 | 71 | 73 |
132-4P | 9.5 | 380 | 50 | 18.7 | 62.5 | 1450 | 86.9% | 0.89 | 2.0 | 2.3 | 7.3 | 71 | 82 |
160-4P | 11 | 380 | 50 | 21.5 | 72.5 | 1450 | 88% | 0.85 | 2.0 | 2.3 | 7.4 | 73 | 116 |
Electric Input: AC/380V/50HZ/3PHASE(Customized Service is
available) Protection Level: IP56/Working Mode: S1/Insulation Class: F/Cooling
mode: IC416/Vibration Level |
