Plasma cutting metal for sale cheap CNC plasama cutting machine
Other plasma metal cutting video pleaseclick:http://xzyahong.en.alibaba.com/custom_page_1/Cutting_video.html
Plasma Cutting Machine Introduction
I.Products advantages:
YH2560 CNC plasma cutting machine is an excellent model designed and manufactured by
Xuzhou Yahong CNC Equipment Factory. Its main characteristics is
that this model uses bilateral drive mode so that the machine can
operate smoothly, have high locating accuracy and simple & good
appearance. Moreover, the modularized design makes machine
components have strong exchangeability and equipment function be
expanded more simply & conveniently. The user can configure plasma
cutting torches in different sizes according to the process
requirements. Its advantages is high automation, easy operation,
high accuracy, high reliability, low price, and simple operation &
maintenance
(1). graphic display function
(2). English interface and other 5 languages
(3). Excellent graph library ,48 graphic
(4). steel plate correction function
(5). Kerf can be automatically compensated
(6). Cutting can continue when power fails
(7). Continuous return can be done
(8). Positioning and cutting can be done randomly
(9). Off-line cutting can be done:
(10). Online upgrading function
III. Main Technical Performance Indexes of products
1 | Product Type | cnc plasma cutting machine |
2 | LCD Display Dimension | 7.0Inches |
3 | Effective Cutting Width (X axis) | 2500mm |
4 | Effective Cutting Length (Y axis) | 6000mm |
5 | Cross Beam Length | 3000mm |
6 | Longitudinal Rail Length | 7500mm |
7 | Cutting Speed | 0-8000mm per minute |
8 | Plasma Cutting Thickness | 2--20mm ( Depends on plasma power source capacity) |
9 | Flame Cutting Thickness | 6--200mm |
10 | Drive Mode | bilateral drive |
11 | Cutting Mode | flame/plasma cut metal |
12 | Ignition device | Auto ignition device |
13 | Height regulating device | Arc voltage height and Electric adjustable high |
14 | File transmission | USB transmission |
15 | Gas Pressure | Max. 0.1Mpa |
16 | Oxygen Pressure | Max.0.7Mpa |
17 | Cutting Gas | Acetylene/Propane |
18 | Plasma Power Source | optional |
19 | Plasma Air | Only pressed Air |
20 | Plasma Air Pressure | Max. 0.8Mpa |
21 | Cutting precision | ±0.5mm National standard JB/T10045.3-99 |
22 | Control accuracy | ±0.01mm |
23 | Power Supply Voltage/Frequency | 220V/110V 50HZ / 60HZ |
24 | Rated Power Supply | 200W |
25 | Working Temperature | -10°C-60°C. Relative Humidity, 0-95%. |
IV.Products Application
V. Operating Steps:
VI.Detail Photos:
Packaging & Shipping
Packing: lining--anti-static film package firstly, waterproof,
moistureproof.
Intermediate--around the perimeter of the box, there is bubble.
Outer--export standard packing, fumigation-free plywood.
Package size: 3600mm*1000mm*1000mm
weight:650KG
VIII.Cutting Samples:
