Features
Non-conductive: Good insulation, assuring a safe system
Smooth surface: Small friction coefficient to ensure the cables go
through smoothly
Fire resistance: Self-extinguishing, do not support combustion
Corrosion Resistance: Resistant to acids, bases and salts, assuring
a lower maintenance cost and a longer performance life
Impact strength: Resistant to compression and impact, suitable to
be buried in concrete
Description
PTFE extruded tubes include ram extruded tubes and paste extruded
tubes. Ram extruded tubes are manufactured from PTFE suspension
resin while paste extruded products from dispersion resin.
Besides virgin PTFE, compounded PTFE are suggested to be used
according to different working conditions. For example, fiberglass,
carbon fiber, graphite, etc. According to customers’ needs, FOROG
can choose the most suitable material for you.
Specifications
RAM EXTRUDED TUBES
OD(mm) | Tolerance (mm) | Wall thickness(mm) | Tolerance (mm) | Length (mm) | Tolerance (mm) |
| 14 | +1.5/-0 | 3 |
2≤T≤3, ±0.2 3<T≤6, ±0.3 |
MAX 6000 |
+20.0/-0 |
| 20 | 2 |
| 20 | 3 |
| 24 | 3 |
| 25 | 2 |
| 28 | 2 |
| 30 | 2 |
| 35 | 2 |
| 35 | 3 |
| 40 | +2.0/-0 | 3 |
| 45 | 3 |
| 51 | 3 |
| 51 | 4 |
| 51 | 5 |
| 65 | 3 |
| 65 | 5 |
| 75.5 | +3.0/-0 | 3 |
| 82 | 4 |
| 82 | 6 |
| 90 | 3 |
| 90 | 5 |
| 102 | +4.0/-0 | 3 |
| 102 | 4 |
| 102 | 5 |
| 126 | 4.5 |
| 158 | 5 |
| 210 | 5 |
| 260 | +5.0/-0 | 5 |
| 310 | 5 |
Only some regular sizes are listed above. Different sizes can be
supplied. Please consult us.
PASTE EXTRUDED TUBES
| OD×ID (mm) | Tolerance (mm) | OD×ID (mm) | Tolerance (mm) |
| 0.8×0.4 | ±0.08 | 12×10 | ±0.2 |
| 1.0×0.5 | ±0.08 | 14×12 | ±0.2 |
| 1.6x0.8 | ±0.08 | 16×14 | ±0.2 |
| 2×1 | ±0.08 | 18×16 | ±0.3 |
| 4×2 | ±0.1 | 20×18 | ±0.3 |
| 6×4 | ±0.1 | 22×20 | ±0.3 |
| 8×6 | ±0.1 | 24×21 | ±0.3 |
| 10×8 | ±0.1 | 28x25 | ±0.3 |
Only some regular sizes are listed above. Different sizes can be
supplied. Please consult us.
