Product Description
R449 AVR

The circuitry of the R449 Voltage Regulator AVR provides closed-loop control of the alternator output voltage by regulating the exciter field current.
The R449 Leroy Somer AVR can be powered by either AREP or the PMG field excitation systems and is fitted as standard on the following alternators:
Ø 8100 Series Alternators
Ø 9100 Series Alternators
Compatible Alternators: LSA51.2, LSA53.1, LSA54

Key specifications
Technology	Analog
Excitation mode	SHUNT, AREP, PMG
Rated excitation current	7 A
Regulation accuracy (+/- %)	0.50%
Frequency range	10 – 100 Hz
Voltage setting range (+/- %)	5%
kU/F limitation	K = 1
Loss of sensing voltage	-
Over-excitation limitation	-
Short circuit current limitation	✓
Voltage droop	✓
Parallel operation between alternators	✓
Load Acceptance Module (LAM)	✓

Specification of R449 AVR:
Ø Steady-state voltage regulation ± 0.5%
Ø Short circuit capability: 3 x Irated for 10 seconds (AREP or PMG excitation)
Ø Voltage sensing:
0-110v Terminals = 95 to 140 volts (50/60 Hz) or
0-220v Terminals = 170 to 260 volts (50/60 Hz) or
0-380v Terminals = 340 to 520 volts (50/60 Hz)
Ø Response time:
Normal (1 sec) for ± 20% voltage variation or Rapid (0.3 sec) for ± 20% voltage variation
Ø Remote voltage adjustment range: ± 5%

Load Adjustment Module (LAM):
On load impact, the rotation speed of the generator set decreases. When it passes below the preset frequency threshold, the LAM causes the voltage to drop by approximately 15%, and consequently, the amount of active load applied is reduced by approximately 25% until the speed reaches its rated value again

Adjustment capability of R449 Alternator AVR:
The R449 Voltage Regulator features the following adjustment capabilities (Please note that no adjustments should be made before careful consultation of the alternator installation and maintenance manual):
n Quadrature droop adjustment
n Alternator output voltage adjustment
n Stability adjustment
n LAM Threshold (under-speed) adjustment
n Excitation ceiling adjustment
n Selection of single-phase or three-phase* voltage sensing
n Selection of normal or rapid response time
n 50 Hz or 60 Hz frequency option
n Remote voltage adjustment option
LAM enable/disable option
