    Metal Face Inductive Proximity Switch , 10 - 30V DC Small Proximity Sensor

    DC M18 metal face inductive proximity switches


    DiameterM18
    Shielded Non-shieldedShieldedNon-shielded
    Switching Distance Sn:(mm)5mm / 8mm8mm
    Housing MaterialStainless steel
    With LED Without LEDWith LED
    Operating Voltage10-30VDC
    Ripple<10%
    No Load Current<10mA
    Max.Load Current150mA
    Leakage Current<0.01mA
    Voltage Drop<1.5V
    Switching Frequency1KHz/500Hz500Hz
    Response Time0.2ms/0.5ms0.5ms
    Switching Hysteresis<15%(Sr)
    Repeat Accuracy<1.0%(Sr)
    Protection CategoryIP67
    Operating Temperature-25°C - +70°C
    Temperature Drift<10%(Sr)
    Short Circuit ProtectionYES
    Overload Trip Point180mA
    EMCRFI>3V/M / EFT>1KV / ESD>4KV(contact)
    Shock/VibrationIEC 60947-5-2,Part 7.4.1 / IEC 60947-5-2,Part 7.4.2
