konnwei car diagnostic scanner CE FCC ROHS KW818 car diagnostic
reader Exhaust gas sensor
KONNWEI KW818 OBDII/EOBD Scanner supports all 10 modes of OBDII
test for a complete diagnosis.
Featuring the unique patented One-Click I/M Readiness Key, TFT
color display and built-in speaker, the KW818 is truly the ultimate
in power and affordability, allowing users to do their jobs faster.
In addition, thousands of troubleshooter code tips help technicians
to save diagnosis and repair time.
Functions:
1. Read and erase fault code from engine, find out failure reason
for check engine light coming on.
3. Turns off Check Engine Light (MIL), warning light, clears codes
and resets monitors
4. Directly show definition of OBDII Codes, without check online.
5. Displays monitor and I/M readiness status (emission status)
6. Reads and display live PCM data stream, live sensor readings, up
to 50 PID/S, and show it in graphical mode.
7. Views freeze frame data to analyze the real cause of engine
failures
8. Displays live O2 oxygen sensor test data
9. Enhanced OBD2 Mode 6 On Board Monitoring Test Results for
Specific Monitored Systems.
10. EVAP System test data
11. Retrieves vehicle information (VIN code, CIN and CVN Number)
12. 12V car battery status check, compare with user manual to
verify if your battery need to be replacement.
13. Data stream storage, and playback even off vehicles.
14. Allows you to print out 3 kinds of stored data: DTCs, Freeze
frame, Live sensor readings. DIY your diagnostic reports available.
15. Troubleshooter code tips guide you to find the root cause of a
trouble code faster, save diagnosis and repair time.
| KW818 is with battery voltage test function | Specification focus on battery test function |
| Function | Test Capacity, test capacity of battery for hearing aids |
| Application | regular or rechargeable batteries, battery pack assembly line,
cylindrical battery, 1.5V battery, button cells |
| Voltage range | 9-12V programmable |
| Oem | Available, Customer Set Voltage & Resistance |
| Type | battery Capacity tester, Battery voltage indicator, 12v Battery
Tester |
| Product name | KW818 car diagnostic reader Exhaust gas sensor |
| Model | konnwei KW818 |
| Compare brand | Compare with Launch Creader VI/AD510/NT301 /OM129 /AL519/ OM126
/NT410/DS808 |
| Connection | KW818 can Connect with Computer by data cable to upgrade system and
review ,storage data on word ,edit data ,print data etc ,KW850
KW830 KW680 KW590 also can be upgrade system and print via. |
| Color | Black /Red For choice |
| Usage | For engine test, detect 12V gasoline and diesel cars |
| Material | ABS housing , Hard Box , Neylon bag |
| Item size (cm) | 20*10*4 |
| package size (cm) | 25*18*8 |
| Item Net weight(kgs) | 0.665 |
| Package Gross weight(Kg) | 0.77W 1W |
| Quantity/cn | 25pcs/cn |
| Carton size(cm) | 55*39*46cm |
| Carton Weight | 20KG/carton |
LCD Screen
Size(Inch) | 2.8inchs black white screen |
| Application | For all 12V cars battery such as vehicles car/ gasoline cars/Hybrid
electric vehicle |
| IC Chip solution | SMT32F103C8T6 Chip solution |
| MOQ | 1PC |
| Language | 6 languages:
English, French, German, Russian, Dutch, Spanish. |
| System | XP WIN7 WIN8 WIN10 |
| Protocol | KW818 protocol availble : ISO 9141, KWP2000, SAE J1850, CAN,J1850
VPW,J1850 PWM. |
| Type | Engine Analyzer, Code Reader, Professional Auto Diagnostic Tool,
Digital Camera, automotive diagnostic tool,o2 oxygen sensor obdii
codes |
| Warranty | 1Year warranty |
| Applicable models | for all kinds of 12v car such as gasoline /diesel //Hybrid electric
vehicle , as see Rover, all cars, Porsche, Saab, Peugeot etc |
| Voltage | 12V |
| Power | 0.77W 1W |
| Type | Code Reader, Auto Diagnostic Tools, Battery Tester, Engine Analyzer |
| Special features | Support data print out, Battery voltage, obd2 scanner, Diagnostic
Fault Code, diagnostic code readers |
| Function | Code Readers & Scan Tools, Vehicle Diagnostic Scanner, Professional
Diagnose Tool, Car diagnosis and troubleshooting, Battery Tester |
| Software version | 2019 Newest, konnwei KW818 support update free and print on
computer |
| Keywords | OBD2 CAN BUS Code Reader, Protocol Car Diagnostic, Car Code Scanner |
| Feature | Multi-language, Car Universal, Support car repair, Supports all
OBDII protocols |
| Item type | Code Readers/ Scan Tools |
| All Konnwei item : |
1.Used For All 12V Gasoline And Diesel Car After 1996 With OBD2
Protocol
2. All our automotive diagnostics products support the following
nine major agreements:
1.SAE J1850 PWM(41.6Kbaud),
2.SAE J1850 VPW(10.4Kbaud)
3.ISO9141-2(5 baud init,10.4Kbaud)
4.ISO14230-4 KWP(5 baud init,10.4 Kbaud)
5.ISO14230-4 KWP(fast init,10.4 Kbaud)
6.ISO15765-4 CAN(11bit ID,500 Kbaud)
7.ISO15765-4 CAN(29bit ID,500 Kbaud)
8.ISO15765-4 CAN(11bit ID,250 Kbaud)
9.ISO15765-4 CAN(29bit ID,250 Kbaud) |
Supports Car Makes:
KW818 supports both diesel and gasoline vehicles, as long as the
car is compliant with standard OBDII protocols, with OBDII 16pins
Diagnostic Port.
American (USA) car
for Standard OBD2 Cars from 1996 to Now:
for Chrysler, for Ford, for GM, for Jeep
European car
for Standard OBD2 Cars from 2004 to Now:
for Alfa Romeo , for SAAB , for Acura , for Opel, for Audi , for
Seat , for Peugeot , for Bentley , for Skoda , for Daewoo, for Benz
, for Daihatsu , for Land Rover, for BMW , for Vauxhall , for
Citroen, for Volvo , for Fiat , for VW , for Ford , for Jaguar
Japanese car
for Standard OBD2 Cars from 2006 to Now:
for KIA, for Isuzu, for Honda , for Mitsubishi, for Hyundai , for
Dacia , for Lexus , for Mazda, for Nissan, for Subaru , for Suzuki,
for Toyota.
Chinese car:
for Standard OBD2 Cars from 2011 to Now
KW818 Car Diagnostic Scanner 6 languages:
English, Spanish, French, Russian,German, Dutch
KW818 Car Diagnostic Scanner Support Protocol:
ISO 9141, KWP2000, SAE J1850, CAN,J1850 VPW,J1850 PWM, support
system: XP WIN7 WIN8 WIN10.
Package list:
1pc x KW818 Super CAN OBDII/EOBDII Memo Scanner
1pc x 1500mm length OBDII Connecting Cable
1pc x COM Cable for connecting KW818 to PC
1pc x User Manual
