    Industrial Self Priming Water Transfer Pump , Non Clog Centrifugal Sewage Pump

    Ask Lasest Price
    Brand Name : Yuzhou
    Model Number : ZW
    Certification : ISO/SGS/CE
    Price : Negotiable
    Payment Terms : T/T, Western Union
    Supply Ability : 500 sets/month
    Delivery Time : 3-7 working days
    • Product Details
    • Company Profile

    Industrial Self Priming Water Transfer Pump , Non Clog Centrifugal Sewage Pump

    ZW non-clog centrifugal sewage pump self-priming water transfer pump industrial chemical dirty water transfer pump

    Product introduction:

    1. ZW horizontal centrifugal pump self priming sewage pump industrial dirty water pump is special designed for sewage and waste water transfer and treatment.

    2. The dirty water pump is with self-priming structure, at the bottom of inlet, there’s a hole for unloading of solids left in pump.

    3. It also could be equipped with diesel engine for wild application.

    4. The unique structure of open impeller makes sure the free pass of solids in sewage with max size of 60% of outlet DN and fiber 150% of impeller diameter.

    5. The self priming sewage pump is widely applicable for the lines of urban discharge projects, light industry, paper making, textile, foodstuff, chemicals, electric power, petroleum, mines, agriculture and so on.


    Products details:

    Working Principle:Centrifugal, Self-priming
    Main applications:Sewage with soilds, dirty water
    Driver:Electric motor, diesel engine
    Power Specs:220/380/400/415V 3phase; 50hz/60hz
    Max.permissible fluid temperature:80°C(176°F)
    Type of connection:Flange
    Installation position:Horizontal
    Casing parts material:Cast iron, Stainless steel
    Shaft seal type:Mechanical seal
    Maximum grain diameter:15-170mm
    Maximum fiber length:120-2000mm
    Maximum viscosity:1×104C.S.T
    Maximum drive rating:55KW(75HP)
    Maximum caliber:300mm(12nch)
    Maximum discharge-side pressure:0.8MPa(8bar)
    Maximum head:80m(262.4ft)
    Flow rate range:8-800m3/h(35.2-3520US.GPM)

    Technical details:

    ModelFlow
    (m3/h)
    Head
    (m)
    Inlet size
    (mm)
    Outlet size
    (mm)
    Speed
    (r/min)
    Motor power
    (kw)
    25ZW8-15815252529001.5
    32ZW10-201020322529002.2
    32ZW20-122012322529002.2
    40ZW20-122012403229002.2
    40ZW10-201020403229002.2
    40ZW15-301530403229003
    50ZW10-201020504029002.2
    50ZW20-122012504029002.2
    50ZW15-301530504029003
    65ZW30-183018655029004
    65ZW20-302030655029005.5
    65ZW15-301530655029003
    65ZW20-152015655014502.2
    65ZW25-402540655029007.5
    65ZW30-5030506550290011
    80ZW40-154015806514504
    80ZW40-5040508065290018.5
    80ZW65-256525806529007.5
    80ZW80-3580358065290015
    80ZW50-6050608065290022
    100ZW100-15100151008029007.5
    100ZW80-20802010080290015
    100ZW80-80808010065290045
    125ZW120-2012020125100145015
    125ZW200-1520015125100145015
    150ZW200-1520015150125145015
    150ZW250-2525025150125290045
    200ZW280-1528015200150145022
    200ZW300-2030020200150145037
    200ZW280-3028030200150145055
    250ZW420-2042020250200145055
    300ZW800-1580015300250145055
